2842140 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

20P,2MM,BRK HDR,DRVT,2.8,0.76AU,

Part	Termination	Contact Finish Thickness - Mating	Contact Length - Mating	Contact Finish - Post	Insulation Material	Contact Material	Connector Type	Material Flammability Rating	Contact Shape	Number of Positions Loaded	Current Rating	Contact Finish - Mating	Pitch - Mating	Number of Positions	Shrouding	Contact Type	Insulation Height	Voltage Rating	Voltage Rating (Type)	Contact Length - Post	Row Spacing - Mating	Number of Rows	Overall Contact Length	Style	Fastening Type	Insulation Color	Mounting Type	Operating Temperature (Max)	Operating Temperature (Min)	Contact Finish Thickness - Post
TE Connectivity AMP Connectors 1-2842140-0	Solder	30 µin	0.157 in	Tin	Thermoplastic	Copper Alloy	Breakaway Header	UL94 V-0	Square	All	2 A	Gold	0.079 in	20	Unshrouded	Male Pin	0.059 in	125 V	DC	0.11 in	0.079 in	2	0.327 in	Board	Push-Pull	Black	Through Hole	125 °C	-40 °C	78.7 µin
TE Connectivity AMP Connectors 2842140-6	Solder	30 µin	0.157 in	Tin	Thermoplastic	Copper Alloy	Breakaway Header	UL94 V-0	Square	All	2 A	Gold	0.079 in	12	Unshrouded	Male Pin	0.059 in	125 V	DC	0.11 in	0.079 in	2	0.327 in	Board	Push-Pull	Black	Through Hole	125 °C	-40 °C	78.7 µin
TE Connectivity AMP Connectors 2842140-7	Solder	30 µin	0.157 in	Tin	Thermoplastic	Copper Alloy	Breakaway Header	UL94 V-0	Square	All	2 A	Gold	0.079 in	14	Unshrouded	Male Pin	0.059 in	125 V	DC	0.11 in	0.079 in	2	0.327 in	Board	Push-Pull	Black	Through Hole	125 °C	-40 °C	78.7 µin
TE Connectivity AMP Connectors 2842140-4	Solder	30 µin	0.157 in	Tin	Thermoplastic	Copper Alloy	Breakaway Header	UL94 V-0	Square	All	2 A	Gold	0.079 in	8	Unshrouded	Male Pin	0.059 in	125 V	DC	0.11 in	0.079 in	2	0.327 in	Board	Push-Pull	Black	Through Hole	125 °C	-40 °C	78.7 µin
TE Connectivity AMP Connectors 2842140-3	Solder	30 µin	0.157 in	Tin	Thermoplastic	Copper Alloy	Breakaway Header	UL94 V-0	Square	All	2 A	Gold	0.079 in	6	Unshrouded	Male Pin	0.059 in	125 V	DC	0.11 in	0.079 in	2	0.327 in	Board	Push-Pull	Black	Through Hole	125 °C	-40 °C	78.7 µin
TE Connectivity AMP Connectors 2842140-5	Solder	30 µin	0.157 in	Tin	Thermoplastic	Copper Alloy	Breakaway Header	UL94 V-0	Square	All	2 A	Gold	0.079 in	10	Unshrouded	Male Pin	0.059 in	125 V	DC	0.11 in	0.079 in	2	0.327 in	Board	Push-Pull	Black	Through Hole	125 °C	-40 °C	78.7 µin
TE Connectivity AMP Connectors 2842140-8	Solder	30 µin	0.157 in	Tin	Thermoplastic	Copper Alloy	Breakaway Header	UL94 V-0	Square	All	2 A	Gold	0.079 in	16	Unshrouded	Male Pin	0.059 in	125 V	DC	0.11 in	0.079 in	2	0.327 in	Board	Push-Pull	Black	Through Hole	125 °C	-40 °C	78.7 µin
TE Connectivity AMP Connectors 2842140-2	Solder	30 µin	0.157 in	Tin	Thermoplastic	Copper Alloy	Breakaway Header	UL94 V-0	Square	All	2 A	Gold	0.079 in	4	Unshrouded	Male Pin	0.059 in	125 V	DC	0.11 in	0.079 in	2	0.327 in	Board	Push-Pull	Black	Through Hole	125 °C	-40 °C	78.7 µin
