FUSE 600V T/D CLASS CD 60A
Description
AI
CCMR060 is a Class CC fuse with an ampere rating of 60.
Beta
⌘K
FUSE 600V T/D CLASS CD 60A
FUSE 600V T/D CLASS CD 60A
| Part | Current Rating | Approval Agency | Applications | Voltage Rating - DC | Response Time | Voltage Rating - AC | Mounting Type | Size / Dimension Length | Size / Dimension Diameter | Breaking Capacity (AC) | Breaking Capacity (DC) | Class | Fuse Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 LITTELFUSE | 60 A | CE CSA UL | Motor Protection | 250 VDC | Slow Blow | 600 VAC | Requires Holder | 1.88 in | 0.85 in | 200 kA | 20 kA | CD | Cartridge |
