MMDP-021 Series
Manufacturer: Omnetics
Beta
⌘K
CABLE ASSY D-MIC-D 21P 457.2MM
| Part | Length | Contact Finish | Type | 2nd Connector | 1st Connector | Shielding | Number of Positions | Color | Contact Finish Thickness | Shell Material | Finish | Number of Rows | Flange Feature | Mounting Type | Connector Layout Pitch | Connector Layout Row to Row | Contact Type | Current Rating (Per Contact) | Connector Type | Termination | Primary Material | Connector Style | Dielectric Material | Contact Material | Contact Form | Shell Material, Finish | Operating Temperature (Max) | Operating Temperature (Min) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omnetics | 1.5 ft | Gold | D-Type Micro-D | Individual Wire Leads | Male Pins Plug | Unshielded | 21 | Individual Multiple | 50 µin | |||||||||||||||||||
 Omnetics | Gold | 21 | 50 µin | Aluminum | Electroless Nickel Nickel Plated | 2 | Housing Shell (Unthreaded) | Free Hanging (In-Line) | 0.05 | 0.05 | Signal | 3 A | Male Pins Plug | Solder Cup | Metal | D-Type Micro-D | Thermoplastic | Copper Alloy | Stamped | Aluminum Electroless Nickel Plated | 125 °C | -55 °C |
