9FGV0431 Series

Catalog

4-OUTPUT 1.8V PCIE GEN 1-4 CLOCK GENERATOR

Part	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Number of Circuits	Main Purpose	Operating Temperature (Min)	Operating Temperature (Max)	Package / Case	PLL	Input	Output	Input Ratio	Output Ratio	Differential Output	Differential Input	Mounting Type	Package Length	Package Name	Package Width	Frequency - Max
Renesas Electronics Corporation 9FGV0431AKILFT	1.9 V	1.7 V	1	PCI Express (PCIe)	-40 °C	85 °C	32-VFQFN Exposed Pad	Yes	Crystal	HCSL LVCMOS	1	5	Yes	No	Surface Mount	5 mm	32-VFQFPN	5 mm	100 MHz
Renesas Electronics Corporation 9FGV0431AKILF	1.9 V	1.7 V	1	PCI Express (PCIe)	-40 °C	85 °C	32-VFQFN Exposed Pad	Yes	Crystal	HCSL LVCMOS	1	5	Yes	No	Surface Mount	5 mm	32-VFQFPN	5 mm	100 MHz
Renesas Electronics Corporation 9FGV0431AKLFT	1.9 V	1.7 V	1	PCI Express (PCIe)	0 °C	70 °C	32-VFQFN Exposed Pad	Yes	Crystal	HCSL LVCMOS	1	5	Yes	No	Surface Mount	5 mm	32-VFQFPN	5 mm	100 MHz
Renesas Electronics Corporation 9FGV0431AKLF	1.9 V	1.7 V	1	PCI Express (PCIe)	0 °C	70 °C	32-VFQFN Exposed Pad	Yes	Crystal	HCSL LVCMOS	1	5	Yes	No	Surface Mount	5 mm	32-VFQFPN	5 mm	100 MHz
