MCP669 Series

Catalog

QUAD, 60MHZ OP W/CS, E TEMP 16 QFN 4X4X0.9MM T/R ROHS COMPLIANT: YES

Part	Current - Supply	Mounting Type	Current - Output / Channel	Voltage - Supply Span (Min)	Output Type	Voltage - Input Offset	Slew Rate	Number of Circuits	Amplifier Type	Gain Bandwidth Product	Current - Input Bias	Package Width	Package Name	Package Length	Voltage - Supply Span (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Package / Case
Microchip Technology MCP669T-E/ML	6 mA	Surface Mount	90 mA	2.5 V	Rail-to-Rail	1.8 mV	32 V/µs	4	General Purpose	60 MHz	6 pA	4 mm	16-QFN	4 mm	5.5 V	125 °C	-40 °C	16-VQFN Exposed Pad
Microchip Technology MCP669-E/ML	6 mA	Surface Mount	90 mA	2.5 V	Rail-to-Rail	1.8 mV	32 V/µs	4	General Purpose	60 MHz	6 pA	4 mm	16-QFN	4 mm	5.5 V	125 °C	-40 °C	16-VQFN Exposed Pad
