AK1 Series
Manufacturer: LITTELFUSE
Beta
⌘K
TVS AXIAL KA RATED - 1KA 76V BI/ BULK
| Part | Capacitance | Voltage - Clamping (Max) | Operating Temperature (Min) | Operating Temperature (Max) | Mounting Type | Bidirectional Channels | Voltage - Breakdown (Min) | Power Line Protection | Package Diameter | Package / Case | Package Name | Right Angle Bend Center | Voltage - Reverse Standoff (Typ) | Current - Peak Pulse | Type | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
LITTELFUSE | 8500 pF | 140 V | -55 °C | 125 °C | Through Hole | 1 | 85 V | No | 24.15 mm | Axial Right Angle Bend | Axial | 24.15 mm | 76 V | 1000 A | Zener | General Purpose |
 LITTELFUSE | 2000 pF | 570 V | -55 °C | 125 °C | Through Hole | 1 | 401 V | No | 24.15 mm | Axial Right Angle Bend | Axial | 24.15 mm | 380 V | 1000 A | Zener | General Purpose |
LITTELFUSE | 2000 pF | 625 V | -55 °C | 125 °C | Through Hole | 1 | 440 V | No | 24.15 mm | Axial Right Angle Bend | Axial | 24.15 mm | 430 V | 1000 A | Zener | General Purpose |
