ISL26102 Series

Catalog

LOW-NOISE 24-BIT DELTA SIGMA ADC

Part	Sampling Rate (Per Second)	Input Type	Architecture	Data Interface	Voltage - Supply, Analog	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Configuration	Mounting Type	Features	Reference Type	Package Width	Package Name	Package Length	Operating Temperature (Min)	Operating Temperature (Max)	Number of A/D Converters	Number of Bits	Number of Inputs
Renesas Electronics Corporation ISL26102AVZ-T	4 kHz	Differential	Sigma-Delta	SPI	5 V	2.7 V	5.25 V	MUX-PGA-ADC	Surface Mount	PGA Temperature Sensor	External	4.4 mm	24-TSSOP	0.173 in	-40 °C	105 °C	1 count	24 bits	2
Renesas Electronics Corporation ISL26102AVZ-T7A	4 kHz	Differential	Sigma-Delta	SPI	5 V	2.7 V	5.25 V	MUX-PGA-ADC	Surface Mount	PGA Temperature Sensor	External	4.4 mm	24-TSSOP	0.173 in	-40 °C	105 °C	1 count	24 bits	2
Renesas Electronics Corporation ISL26102AVZ	4 kHz	Differential	Sigma-Delta	SPI	5 V	2.7 V	5.25 V	MUX-PGA-ADC	Surface Mount	PGA Temperature Sensor	External	4.4 mm	24-TSSOP	0.173 in	-40 °C	105 °C	1 count	24 bits	2
