ISL43410 Series

Catalog

LOW-VOLTAGE, SINGLE SUPPLY, DPDT HIGH PERFORMANCE ANALOG SWITCH

Part	Switch Circuit Type	Switch Time Ton (Max)	Switch Time Toff (Typ)	Crosstalk	Channel-to-Channel Matching (ΔRon)	Number of Circuits	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Supply, Single (V+) (Maximum)	Voltage - Supply, Single (V+) (Minimum)	Package Length	Package Name	Package Width	Current - Leakage (Max)	Charge Injection	On-State Resistance (Max)	Multiplexer Inputs	Demultiplexer Outputs	Channel Capacitance (CD(off))	Channel Capacitance (CS(off))	Mounting Type	Package / Case
Renesas Electronics Corporation ISL43410IUZ-T	DPDT	25 ns	24 ns	-85 dB	500 mOhm	1	85 °C	-40 °C	12 V	2.7 V	0.118 in	10-MSOP 10-TFSOP	3 mm	3 nA	1.2 pC	50 Ohms	2	2	6 pF	4 pF	Surface Mount
Renesas Electronics Corporation ISL43410IUZ	DPDT	25 ns	24 ns	-85 dB	500 mOhm	1	85 °C	-40 °C	12 V	2.7 V	0.118 in	10-MSOP 10-TFSOP	3 mm	3 nA	1.2 pC	50 Ohms	2	2	6 pF	4 pF	Surface Mount
Renesas Electronics Corporation ISL43410IR	DPDT	25 ns	24 ns	-85 dB	500 mOhm	1	85 °C	-40 °C	12 V	2.7 V	3 mm	16-QFN	3 mm	3 nA	1.2 pC	50 Ohms	2	2	6 pF	4 pF	Surface Mount	16-VFQFN Exposed Pad
Renesas Electronics Corporation ISL43410IU	DPDT	25 ns	24 ns	-85 dB	500 mOhm	1	85 °C	-40 °C	12 V	2.7 V	0.118 in	10-MSOP 10-TFSOP	3 mm	3 nA	1.2 pC	50 Ohms	2	2	6 pF	4 pF	Surface Mount
