796636 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
TERM BLOCK HDR 20POS VERT 5.08MM
| Part | Number of Positions | Header Orientation | Type | Voltage - UL | Contact Tail Length | Contact Tail Length | Positions Per Level | Termination Style | Number of Levels | Contact Mating Finish | Mounting Type | Contact Material | Insulation Height | Insulation Height | Material Flammability Rating | Color | Operating Temperature [Min] | Operating Temperature [Max] | Pitch [x] | Pitch [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | 20 | Vertical | Header Male Pins Shrouded (4 Side) | 300 V | 3.5 mm | 0.138 in | 20 | Solder | 1 | Tin | Through Hole | Copper Alloy | 0.472 in | 12 mm | UL94 V-0 | Green | -40 °C | 110 °C | 0.2 in | 5.08 mm |
TE Connectivity Raychem Cable Protection | 15 | Vertical | Header Male Pins Shrouded (4 Side) | 300 V | 3.5 mm | 0.138 in | 15 | Solder | 1 | Tin | Through Hole | Copper Alloy | 0.472 in | 12 mm | UL94 V-0 | Green | -40 °C | 110 °C | 0.2 in | 5.08 mm |
 TE Connectivity Raychem Cable Protection | 8 | Vertical | Header Male Pins Shrouded (4 Side) | 300 V | 3.5 mm | 0.138 in | 8 | Solder | 1 | Tin | Through Hole | Copper Alloy | 0.472 in | 12 mm | UL94 V-0 | Green | -40 °C | 110 °C | 0.2 in | 5.08 mm |
 TE Connectivity Raychem Cable Protection | 6 | Vertical | Header Male Pins Shrouded (4 Side) | 300 V | 3.5 mm | 0.138 in | 6 | Solder | 1 | Tin | Through Hole | Copper Alloy | 0.472 in | 12 mm | UL94 V-0 | Green | -40 °C | 110 °C | 0.2 in | 5.08 mm |
TE Connectivity Raychem Cable Protection | 19 | Vertical | Header Male Pins Shrouded (4 Side) | 300 V | 3.5 mm | 0.138 in | 19 | Solder | 1 | Tin | Through Hole | Copper Alloy | 0.472 in | 12 mm | UL94 V-0 | Green | -40 °C | 110 °C | 0.2 in | 5.08 mm |
TE Connectivity Raychem Cable Protection | 11 | Vertical | Header Male Pins Shrouded (4 Side) | 300 V | 3.5 mm | 0.138 in | 11 | Solder | 1 | Tin | Through Hole | Copper Alloy | 0.472 in | 12 mm | UL94 V-0 | Green | -40 °C | 110 °C | 0.2 in | 5.08 mm |
TE Connectivity Raychem Cable Protection | 7 | Vertical | Header Male Pins Shrouded (4 Side) | 300 V | 3.5 mm | 0.138 in | 7 | Solder | 1 | Tin | Through Hole | Copper Alloy | 0.472 in | 12 mm | UL94 V-0 | Green | -40 °C | 110 °C | 0.2 in | 5.08 mm |
TE Connectivity Raychem Cable Protection | 13 | Vertical | Header Male Pins Shrouded (4 Side) | 300 V | 3.5 mm | 0.138 in | 13 | Solder | 1 | Tin | Through Hole | Copper Alloy | 0.472 in | 12 mm | UL94 V-0 | Green | -40 °C | 110 °C | 0.2 in | 5.08 mm |
 TE Connectivity Raychem Cable Protection | 10 | Vertical | Header Male Pins Shrouded (4 Side) | 300 V | 3.5 mm | 0.138 in | 10 | Solder | 1 | Tin | Through Hole | Copper Alloy | 0.472 in | 12 mm | UL94 V-0 | Green | -40 °C | 110 °C | 0.2 in | 5.08 mm |
TE Connectivity Raychem Cable Protection | 9 | Vertical | Header Male Pins Shrouded (4 Side) | 300 V | 3.5 mm | 0.138 in | 9 | Solder | 1 | Tin | Through Hole | Copper Alloy | 0.472 in | 12 mm | UL94 V-0 | Green | -40 °C | 110 °C | 0.2 in | 5.08 mm |
