1969582 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

ASSY, HDR, VERT, NO-BOSS, DUAL ROW,EP2.5

Part	Contact Finish - Mating	Contact Type	Contact Shape	Number of Positions	Number of Positions Loaded	Shrouding	Contact Material	Pitch - Mating	Mounting Type	Fastening Type	Row Spacing - Mating	Connector Type	Insulation Color	Contact Length - Post	Voltage Rating	Style	Material Flammability Rating	Current Rating	Insulation Height	Contact Finish - Post	Operating Temperature (Min)	Operating Temperature (Max)	Number of Rows	Insulation Material	Termination	Applications
TE Connectivity AMP Connectors 1-1969582-8	Tin	Male Pin	Circular	18	All	Shrouded - 4 Wall	Brass	0.098 in	Through Hole	Friction Lock	0.098 in	Header	White	0.134 in	250 V	Board Cable/Wire	UL94 V-0	4.2 A	0.386 in	Tin	-55 °C	105 °C	2	Nylon 6/6 Polyamide (PA66)	Kinked Pin Solder	General Purpose Industrial Lighting
TE Connectivity AMP Connectors 3-1969582-8	Tin	Male Pin	Circular	38	All	Shrouded - 4 Wall	Brass	0.098 in	Through Hole	Friction Lock	0.098 in	Header	White	0.134 in	250 V	Board Cable/Wire	UL94 V-0	4.2 A	0.386 in	Tin	-55 °C	105 °C	2	Nylon 6/6 Polyamide (PA66)	Kinked Pin Solder	General Purpose Industrial Lighting
TE Connectivity AMP Connectors 2-1969582-6	Tin	Male Pin	Circular	26	All	Shrouded - 4 Wall	Brass	0.098 in	Through Hole	Friction Lock	0.098 in	Header	White	0.134 in	250 V	Board Cable/Wire	UL94 V-0	4.2 A	0.386 in	Tin	-55 °C	105 °C	2	Nylon 6/6 Polyamide (PA66)	Kinked Pin Solder	General Purpose Industrial Lighting
TE Connectivity AMP Connectors 3-1969582-4	Tin	Male Pin	Circular	34	All	Shrouded - 4 Wall	Brass	0.098 in	Through Hole	Friction Lock	0.098 in	Header	White	0.134 in	250 V	Board Cable/Wire	UL94 V-0	4.2 A	0.386 in	Tin	-55 °C	105 °C	2	Nylon 6/6 Polyamide (PA66)	Kinked Pin Solder	General Purpose Industrial Lighting
TE Connectivity AMP Connectors 1-1969582-2	Tin	Male Pin	Circular	12	All	Shrouded - 4 Wall	Brass	0.098 in	Through Hole	Friction Lock	0.098 in	Header	White	0.134 in	250 V	Board Cable/Wire	UL94 V-0	4.2 A	0.386 in	Tin	-55 °C	105 °C	2	Nylon 6/6 Polyamide (PA66)	Kinked Pin Solder	General Purpose Industrial Lighting
TE Connectivity AMP Connectors 1-1969582-6	Tin	Male Pin	Circular	16	All	Shrouded - 4 Wall	Brass	0.098 in	Through Hole	Friction Lock	0.098 in	Header	White	0.134 in	250 V	Board Cable/Wire	UL94 V-0	4.2 A	0.386 in	Tin	-55 °C	105 °C	2	Nylon 6/6 Polyamide (PA66)	Kinked Pin Solder	General Purpose Industrial Lighting
TE Connectivity AMP Connectors 1969582-8	Tin	Male Pin	Circular	8	All	Shrouded - 4 Wall	Brass	0.098 in	Through Hole	Friction Lock	0.098 in	Header	White	0.134 in	250 V	Board Cable/Wire	UL94 V-0	4.2 A	0.386 in	Tin	-55 °C	105 °C	2	Nylon 6/6 Polyamide (PA66)	Kinked Pin Solder	General Purpose Industrial Lighting
