2842127 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

BOARD TO BOARD & MEZZANINE CONNECTORS 4P,2MM,BRK HDR,DRVT,2.8,0.38AU,TB

Part	Overall Contact Length	Style	Material Flammability Rating	Voltage Rating	Voltage Rating (Type)	Connector Type	Contact Length - Mating	Insulation Height	Pitch - Mating	Fastening Type	Number of Positions	Contact Finish Thickness - Mating	Contact Type	Contact Shape	Operating Temperature (Max)	Operating Temperature (Min)	Contact Finish - Mating	Contact Finish - Post	Number of Rows	Insulation Color	Contact Length - Post	Row Spacing - Mating	Shrouding	Termination	Current Rating	Contact Material	Insulation Material	Mounting Type	Number of Positions Loaded	Contact Finish Thickness - Post
TE Connectivity AMP Connectors 2842127-2	0.327 in	Board	UL94 V-0	125 V	DC	Breakaway Header	0.157 in	0.059 in	0.079 in	Push-Pull	4	15 µin	Male Pin	Square	125 °C	-40 °C	Gold	Tin	2	Black	0.11 in	0.079 in	Unshrouded	Solder	2 A	Copper Alloy	Thermoplastic	Through Hole	All	78.7 µin
TE Connectivity AMP Connectors 2842127-4	0.327 in	Board	UL94 V-0	125 V	DC	Breakaway Header	0.157 in	0.059 in	0.079 in	Push-Pull	8	15 µin	Male Pin	Square	125 °C	-40 °C	Gold	Tin	2	Black	0.11 in	0.079 in	Unshrouded	Solder	2 A	Copper Alloy	Thermoplastic	Through Hole	All	78.7 µin
TE Connectivity AMP Connectors 2842127-7	0.327 in	Board	UL94 V-0	125 V	DC	Breakaway Header	0.157 in	0.059 in	0.079 in	Push-Pull	14	15 µin	Male Pin	Square	125 °C	-40 °C	Gold	Tin	2	Black	0.11 in	0.079 in	Unshrouded	Solder	2 A	Copper Alloy	Thermoplastic	Through Hole	All	78.7 µin
TE Connectivity AMP Connectors 2842127-6	0.327 in	Board	UL94 V-0	125 V	DC	Breakaway Header	0.157 in	0.059 in	0.079 in	Push-Pull	12	15 µin	Male Pin	Square	125 °C	-40 °C	Gold	Tin	2	Black	0.11 in	0.079 in	Unshrouded	Solder	2 A	Copper Alloy	Thermoplastic	Through Hole	All	78.7 µin
TE Connectivity AMP Connectors 2842127-8	0.327 in	Board	UL94 V-0	125 V	DC	Breakaway Header	0.157 in	0.059 in	0.079 in	Push-Pull	16	15 µin	Male Pin	Square	125 °C	-40 °C	Gold	Tin	2	Black	0.11 in	0.079 in	Unshrouded	Solder	2 A	Copper Alloy	Thermoplastic	Through Hole	All	78.7 µin
TE Connectivity AMP Connectors 2842127-5	0.327 in	Board	UL94 V-0	125 V	DC	Breakaway Header	0.157 in	0.059 in	0.079 in	Push-Pull	10	15 µin	Male Pin	Square	125 °C	-40 °C	Gold	Tin	2	Black	0.11 in	0.079 in	Unshrouded	Solder	2 A	Copper Alloy	Thermoplastic	Through Hole	All	78.7 µin
TE Connectivity AMP Connectors 1-2842127-0	0.327 in	Board	UL94 V-0	125 V	DC	Breakaway Header	0.157 in	0.059 in	0.079 in	Push-Pull	20	15 µin	Male Pin	Square	125 °C	-40 °C	Gold	Tin	2	Black	0.11 in	0.079 in	Unshrouded	Solder	2 A	Copper Alloy	Thermoplastic	Through Hole	All	78.7 µin
TE Connectivity AMP Connectors 2842127-3	0.327 in	Board	UL94 V-0	125 V	DC	Breakaway Header	0.157 in	0.059 in	0.079 in	Push-Pull	6	15 µin	Male Pin	Square	125 °C	-40 °C	Gold	Tin	2	Black	0.11 in	0.079 in	Unshrouded	Solder	2 A	Copper Alloy	Thermoplastic	Through Hole	All	78.7 µin
