2363962 Series

Catalog

0.4MM BTB CONN H0.8 PLUG ASSEMBLY, 20P

Part	Number of Positions	Pitch	Contact Finish Thickness (string set options)	Contact Finish Thickness	Mated Stacking Height	Features	Connector Type	Height Above Board	Contact Finish	Number of Rows	Mounting Type
TE Connectivity AMP Connectors 2-2363962-0	20	0.016 in	Flash	Flash	0.8 mm	Solder Retention	Outer Shroud Contacts Plug	0.025 in	Gold	2	Surface Mount
TE Connectivity AMP Connectors 4-2363962-0	40	0.016 in	Flash	Flash	0.8 mm	Solder Retention	Outer Shroud Contacts Plug	0.025 in	Gold	2	Surface Mount
TE Connectivity AMP Connectors 2-2363962-4	24 pos	0.016 in	Flash	Flash	0.8 mm	Solder Retention	Outer Shroud Contacts Plug	0.025 in	Gold	2	Surface Mount
TE Connectivity AMP Connectors 3-2363962-0	30	0.016 in	Flash	Flash	0.8 mm	Solder Retention	Outer Shroud Contacts Plug	0.025 in	Gold	2	Surface Mount
