ELR Series

Catalog

TERMINAL BLOCK INTERFACE MODULES ELR H3-IES-SC- 24DC/ 500AC-0,6

Part	Wattage - Load	Type	Voltage - Load (Min)	Voltage - Load (Max)	Current - Output	Mounting Type	Voltage - Supply	Operating Temperature (Max)	Operating Temperature (Min)	Number of Motors	Control / Drive Type	Motor Type	Weight	Output Type	Package / Case	Circuit	Termination Style	Load Current	Voltage - Input
Phoenix Contact 2900566	2.5 W 300 W	Module	42 V	550 V	600 mA	DIN Rail	24 VDC	70 °C	-25 °C	1	Motor Starter Reversible	AC Motor
Phoenix Contact 2900542	2.5 W 300 W	Module	42 V	550 V	600 mA	DIN Rail	24 VDC	70 °C	-25 °C	1	Motor Starter Reversible	AC Motor	0.662 lb
Phoenix Contact 2900570	7 W 4500 W	Module	42 V	550 V	9 A	DIN Rail	230 VAC	70 °C	-25 °C	1	Motor Starter Reversible	AC Motor	0.662 lb
Phoenix Contact 2297374			48 V	575 V		DIN Rail								AC Zero Cross	SSR with Integrated Heat Sink	3PST-NO (3 Form A)	Screw Terminal	37 A	24 V
Phoenix Contact 2297057			48 V	550 V		DIN Rail								AC	Module	3PST-NO (3 Form A)	Screw Terminal	9 A	24 V
Phoenix Contact 2964186		Module	110 V	550 V	9 A	DIN Rail	24 VDC	60 °C	-20 °C	1	Reversing Relay	AC Motor	1.7 lbs
