282843 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

TERM BLK 8P SIDE ENT 10.16MM PCB

Part	Features	Current	Wire Gauge (AWG) (Min)	Wire Gauge (AWG) (Max)	Voltage	Color	Pitch	Number of Levels	Wire Termination	Mating Orientation	Mounting Type	Positions Per Level	Contact Material	Plating	Screw Material	Screw Plating	Clamp Material	Clamp Plating	Screw Thread	Housing Material	Torque - Screw
TE Connectivity AMP Connectors 282843-8	Interlocking (Side)	17.5 A	12 AWG	30 AWG	600 V	Green	0.4 in	1	Rising Cage Clamp Screw	Horizontal with Board	Through Hole	8	Brass	Tin Plated	Brass	Nickel Plated	Brass	Nickel Plated	M3	Nylon 6/6 PA66 Polyamide	0.79 Nm
TE Connectivity AMP Connectors 282843-7	Interlocking (Side)	17.5 A	12 AWG	30 AWG	600 V	Green	0.4 in	1	Rising Cage Clamp Screw	Horizontal with Board	Through Hole	7	Brass	Tin Plated	Brass	Nickel Plated	Brass	Nickel Plated	M3	Nylon 6/6 PA66 Polyamide	0.79 Nm
TE Connectivity AMP Connectors 282843-9	Interlocking (Side)	17.5 A	12 AWG	30 AWG	600 V	Green	0.4 in	1	Rising Cage Clamp Screw	Horizontal with Board	Through Hole	9	Brass	Tin Plated	Brass	Nickel Plated	Brass	Nickel Plated	M3	Nylon 6/6 PA66 Polyamide	0.79 Nm
TE Connectivity AMP Connectors 282843-2	Interlocking (Side)	17.5 A	12 AWG	30 AWG	600 V	Green	0.4 in	1	Rising Cage Clamp Screw	Horizontal with Board	Through Hole	2	Brass	Tin Plated	Brass	Nickel Plated	Brass	Nickel Plated	M3	Nylon 6/6 PA66 Polyamide	0.79 Nm
TE Connectivity AMP Connectors 1-282843-1	Interlocking (Side)	17.5 A	12 AWG	30 AWG	600 V	Green	0.4 in	1	Rising Cage Clamp Screw	Horizontal with Board	Through Hole	11	Brass	Tin Plated	Brass	Nickel Plated	Brass	Nickel Plated	M3	Nylon 6/6 PA66 Polyamide	0.79 Nm
TE Connectivity AMP Connectors 282843-3	Interlocking (Side)	17.5 A	12 AWG	30 AWG	600 V	Green	0.4 in	1	Rising Cage Clamp Screw	Horizontal with Board	Through Hole	3	Brass	Tin Plated	Brass	Nickel Plated	Brass	Nickel Plated	M3	Nylon 6/6 PA66 Polyamide	0.79 Nm
