2355172 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

BOARD TO BOARD & MEZZANINE CONNECTORS 8P,2MM,BRK HDR,SRVT,2.8,0.1AU,BOX

Part	Termination	Number of Positions	Contact Material	Pitch - Mating	Contact Finish Thickness - Mating	Contact Length - Mating	Contact Finish - Post	Style	Insulation Material	Number of Rows	Connector Type	Voltage Rating	Voltage Rating (Type)	Contact Finish - Mating	Insulation Height	Number of Positions Loaded	Mounting Type	Operating Temperature (Max)	Operating Temperature (Min)	Material Flammability Rating	Contact Shape	Insulation Color	Contact Type	Fastening Type	Shrouding	Contact Length - Post	Current Rating	Overall Contact Length	Contact Finish Thickness - Post
TE Connectivity AMP Connectors 2355172-8	Solder	8	Copper Alloy	0.079 in	3.94 µin	0.157 in	Tin	Board	Thermoplastic	1	Breakaway Header	125 V	DC	Gold	0.059 in	All	Through Hole	125 °C	-40 °C	UL94 V-0	Square	Black	Male Pin	Push-Pull	Unshrouded	0.11 in	2 A	0.327 in	78.7 µin
TE Connectivity AMP Connectors 2355172-3	Solder	3	Copper Alloy	0.079 in	3.94 µin	0.157 in	Tin	Board	Thermoplastic	1	Breakaway Header	125 V	DC	Gold	0.059 in	All	Through Hole	125 °C	-40 °C	UL94 V-0	Square	Black	Male Pin	Push-Pull	Unshrouded	0.11 in	2 A	0.327 in	78.7 µin
TE Connectivity AMP Connectors 1-2355172-0	Solder	10	Copper Alloy	0.079 in	3.94 µin	0.157 in	Tin	Board	Thermoplastic	1	Breakaway Header	125 V	DC	Gold	0.059 in	All	Through Hole	125 °C	-40 °C	UL94 V-0	Square	Black	Male Pin	Push-Pull	Unshrouded	0.11 in	2 A	0.327 in	78.7 µin
TE Connectivity AMP Connectors 2355172-4	Solder	4	Copper Alloy	0.079 in	3.94 µin	0.157 in	Tin	Board	Thermoplastic	1	Breakaway Header	125 V	DC	Gold	0.059 in	All	Through Hole	125 °C	-40 °C	UL94 V-0	Square	Black	Male Pin	Push-Pull	Unshrouded	0.11 in	2 A	0.327 in	78.7 µin
TE Connectivity AMP Connectors 2355172-6	Solder	6	Copper Alloy	0.079 in	3.94 µin	0.157 in	Tin	Board	Thermoplastic	1	Breakaway Header	125 V	DC	Gold	0.059 in	All	Through Hole	125 °C	-40 °C	UL94 V-0	Square	Black	Male Pin	Push-Pull	Unshrouded	0.11 in	2 A	0.327 in	78.7 µin
TE Connectivity AMP Connectors 2355172-2	Solder	2	Copper Alloy	0.079 in	3.94 µin	0.157 in	Tin	Board	Thermoplastic	1	Breakaway Header	125 V	DC	Gold	0.059 in	All	Through Hole	125 °C	-40 °C	UL94 V-0	Square	Black	Male Pin	Push-Pull	Unshrouded	0.11 in	2 A	0.327 in	78.7 µin
TE Connectivity AMP Connectors 2355172-5	Solder	5	Copper Alloy	0.079 in	3.94 µin	0.157 in	Tin	Board	Thermoplastic	1	Breakaway Header	125 V	DC	Gold	0.059 in	All	Through Hole	125 °C	-40 °C	UL94 V-0	Square	Black	Male Pin	Push-Pull	Unshrouded	0.11 in	2 A	0.327 in	78.7 µin
