MIC5305 Series

Catalog

IC REG LIN 2.6V 150MA TSOT23-5

Part	Voltage - Input (Max)	Output Configuration	Protection Features	Package / Case	Operating Temperature (Max)	Operating Temperature (Min)	Current - Quiescent (Iq)	Mounting Type	Voltage - Output (Min/Fixed)	Current - Output	PSRR (Maximum)	PSRR (Minimum)	Package Name	Control Features	Number of Regulators	Output Type	Voltage Dropout (Max)	Package Length	Package Width	Voltage - Output (Max)
Microchip Technology MIC5305-2.6BD5-TR	5.5 V	Positive	Over Current Over Temperature	SOT-23-5 Thin TSOT-23-5	125 °C	-40 °C	150 µA	Surface Mount	2.6 V	150 mA	85 dB	65 dB	TSOT-23-5	Enable	1	Fixed
Microchip Technology MIC5305-3.0YML-TR	5.5 V	Positive	Over Current Over Temperature	6-MLF® 6-VDFN Exposed Pad	125 °C	-40 °C	150 µA	Surface Mount	3 V	150 mA	85 dB	65 dB	6-DFN	Enable	1	Fixed	0.85 V	2 mm	2 mm
Microchip Technology MIC5305-2.9BML-TR	5.5 V	Positive	Over Current Over Temperature	6-MLF® 6-VDFN Exposed Pad	125 °C	-40 °C	150 µA	Surface Mount	2.9 V	150 mA	85 dB	65 dB	6-DFN	Enable	1	Fixed	0.85 V	2 mm	2 mm
Microchip Technology MIC5305-2.9YD5-TR	5.5 V	Positive	Over Current Over Temperature	SOT-23-5 Thin TSOT-23-5	125 °C	-40 °C	150 µA	Surface Mount	2.9 V	150 mA	85 dB	65 dB	TSOT-23-5	Enable	1	Fixed	0.85 V
Microchip Technology MIC5305-3.0YD5-TR	5.5 V	Positive	Over Current Over Temperature	SOT-23-5 Thin TSOT-23-5	125 °C	-40 °C	150 µA	Surface Mount	3 V	150 mA	85 dB	65 dB	TSOT-23-5	Enable	1	Fixed	0.85 V
Microchip Technology MIC5305-2.5BML-TR	5.5 V	Positive	Over Current Over Temperature	6-MLF® 6-VDFN Exposed Pad	125 °C	-40 °C	150 µA	Surface Mount	2.5 V	150 mA	85 dB	65 dB	6-DFN	Enable	1	Fixed		2 mm	2 mm
Microchip Technology MIC5305-3.0BML-TR	5.5 V	Positive	Over Current Over Temperature	6-MLF® 6-VDFN Exposed Pad	125 °C	-40 °C	150 µA	Surface Mount	3 V	150 mA	85 dB	65 dB	6-DFN	Enable	1	Fixed	0.85 V	2 mm	2 mm
Microchip Technology MIC5305-3.3YD5-TR	5.5 V	Positive	Over Current Over Temperature	SOT-23-5 Thin TSOT-23-5	125 °C	-40 °C	150 µA	Surface Mount	3.3 V	150 mA	85 dB	65 dB	TSOT-23-5	Enable	1	Fixed	0.85 V
Microchip Technology MIC5305BML-TR	5.5 V	Positive	Over Current Over Temperature	6-MLF® 6-VDFN Exposed Pad	125 °C	-40 °C	150 µA	Surface Mount	1.25 V	150 mA	85 dB	65 dB	6-DFN	Enable	1	Adjustable	0.85 V	2 mm	2 mm	5.5 V
Microchip Technology MIC5305-4.6YMT-TR	5.5 V	Positive	Over Current Over Temperature	6-TMLF® 6-UDFN Exposed Pad	125 °C	-40 °C	150 µA	Surface Mount	4.6 V	150 mA	85 dB	65 dB	6-TMLF®	Enable	1	Fixed	0.85 V	2 mm	2 mm
