1986775 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
SCREWLESS, SW,6P,5.08 PCB, LOW AMP
| Part | Clamp Material - Plating | Housing Material | Plating | Contact Material | Operating Temperature (Min) | Operating Temperature (Max) | Current | Pitch | Color | Mounting Type | Mating Orientation | Positions Per Level | Wire Termination | Number of Levels | Voltage | Wire Gauge |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Steel | Nylon PA Polyamide | Tin Plated | Copper Alloy | -40 °C | 110 °C | 15 A | 5.08 mm | Green | Through Hole | Horizontal with Board | 6 | Push Button Clamp Screwless | 1 | 300 V | 12 AWG |
TE Connectivity AMP Connectors | Steel | Nylon PA Polyamide | Tin Plated | Copper Alloy | -40 °C | 110 °C | 15 A | 5.08 mm | Green | Through Hole | Horizontal with Board | 8 | Push Button Clamp Screwless | 1 | 300 V | 12 AWG |
