ISL28233 Series

Catalog

DUAL MICROPOWER, CHOPPER STABILIZED, RRIO OPERATIONAL AMPLIFIER

Part	Slew Rate	Gain Bandwidth Product	Amplifier Type	Package Width	Package Name	Package Length	Current - Output / Channel	Operating Temperature (Max)	Operating Temperature (Min)	Current - Supply	Number of Circuits	Package / Case	Mounting Type	Voltage - Supply Span (Max)	Voltage - Input Offset	Current - Input Bias	Voltage - Supply Span (Min)	Output Type
Renesas Electronics Corporation ISL28233FRZ-T7A	0.2 V/µs	400 kHz	Zero-Drift	3 mm	8-DFN	3 mm	19 mA	125 °C	-40 °C	18 µA	2	8-VDFN Exposed Pad	Surface Mount	6 V	2 µV	180 pA	1.8 V	Rail-to-Rail
Renesas Electronics Corporation ISL28233FRZ-T13	0.2 V/µs	400 kHz	Zero-Drift	3 mm	8-DFN	3 mm	19 mA	125 °C	-40 °C	18 µA	2	8-VDFN Exposed Pad	Surface Mount	6 V	2 µV	180 pA	1.8 V	Rail-to-Rail
Renesas Electronics Corporation ISL28233FRZ-T7	0.2 V/µs	400 kHz	Zero-Drift	3 mm	8-DFN	3 mm	19 mA	125 °C	-40 °C	18 µA	2	8-VDFN Exposed Pad	Surface Mount	6 V	2 µV	180 pA	1.8 V	Rail-to-Rail
Renesas Electronics Corporation ISL28233FUZ	0.2 V/µs	400 kHz	Zero-Drift	3 mm	8-MSOP 8-TSSOP 8-MSOP	0.118 in	19 mA	125 °C	-40 °C	18 µA	2		Surface Mount	6 V	2 µV	180 pA	1.8 V	Rail-to-Rail
Renesas Electronics Corporation ISL28233FUZ-T7	0.2 V/µs	400 kHz	Zero-Drift	3 mm	8-MSOP 8-TSSOP 8-MSOP	0.118 in	19 mA	125 °C	-40 °C	18 µA	2		Surface Mount	6 V	2 µV	180 pA	1.8 V	Rail-to-Rail
Renesas Electronics Corporation ISL28233IUZ-T7	0.2 V/µs	400 kHz	Zero-Drift	3 mm	8-MSOP 8-TSSOP 8-MSOP	0.118 in	17 mA	85 °C	-40 °C	18 µA	2		Surface Mount	5.5 V	2 µV	300 pA	1.8 V	Rail-to-Rail
