PIC32MK0512GPE064 Series

High Performance 32-Bit MCU with FPU & DSP

Catalog

High Performance 32-Bit MCU with FPU & DSP

Part	Peripherals	Voltage - Supply (Vcc/Vdd) Minimum	Voltage - Supply (Vcc/Vdd) Maximum	EEPROM Size (Width)	EEPROM Size (Depth)	Core Processor	Operating Temperature (Max)	Operating Temperature (Min)	Program Memory Width	Program Memory Size	Program Memory Depth	Package / Case	Program Memory Type	Package Width	Package Name	Package Length	RAM Size Width	RAM Size Depth	Core Size (Bit Width)	Connectivity	Number of I/O	Oscillator Type	Grade	A/D Resolution (bits)	A/D Channels	Mounting Type	Qualification	Speed	Core Configuration
Microchip Technology PIC32MK0512GPE064-E/PT	Brown-out Detect DMA I2S POR Reset WDT	2.2 V	3.6 V	8 bit	4 K	MIPS32® microAptiv™	125 °C	-40 °C	8 bit	512 KB	512 K	64-TQFP	FLASH	10 mm	64-TQFP	10 mm	8 bit	128 K	32 Bit	Brown Brown-out Detect/Reset DMA I2S out Detect POR Reset WDT	48	Internal	Automotive	12 bit	26 count	Surface Mount	AEC-Q100	80 MHz	Single-Core
Microchip Technology PIC32MK0512GPE064T-E/PT	Brown-out Detect DMA I2S POR Reset WDT	2.2 V	3.6 V	8 bit	4 K	MIPS32® microAptiv™	125 °C	-40 °C	8 bit	512 KB	512 K	64-TQFP	FLASH	10 mm	64-TQFP	10 mm	8 bit	128 K	32 Bit	Brown Brown-out Detect/Reset DMA I2S out Detect POR Reset WDT	48	Internal	Automotive	12 bit	26 count	Surface Mount	AEC-Q100	80 MHz	Single-Core
Microchip Technology PIC32MK0512GPE064T-I/MR	Brown-out Detect DMA I2S POR Reset WDT	2.2 V	3.6 V	8 bit	4 K	MIPS32® microAptiv™	85 °C	-40 °C	8 bit	512 KB	512 K	64-VFQFN Exposed Pad	FLASH	9 mm	64-QFN	9 mm	8 bit	128 K	32 Bit	Brown Brown-out Detect/Reset DMA I2S out Detect POR Reset WDT	48	Internal		12 bit	26 count	Surface Mount		120 MHz
Microchip Technology PIC32MK0512GPE064-I/PT	Brown-out Detect DMA I2S POR Reset WDT	2.2 V	3.6 V	8 bit	4 K	MIPS32® microAptiv™	85 °C	-40 °C	8 bit	512 KB	512 K	64-TQFP	FLASH	10 mm	64-TQFP	10 mm	8 bit	128 K	32 Bit	Brown Brown-out Detect/Reset DMA I2S out Detect POR Reset WDT	48	Internal		12 bit	26 count	Surface Mount		120 MHz
Microchip Technology PIC32MK0512GPE064T-I/PT	Brown-out Detect DMA I2S POR Reset WDT	2.2 V	3.6 V	8 bit	4 K	MIPS32® microAptiv™	85 °C	-40 °C	8 bit	512 KB	512 K	64-TQFP	FLASH	10 mm	64-TQFP	10 mm	8 bit	128 K	32 Bit	Brown Brown-out Detect/Reset DMA I2S out Detect POR Reset WDT	48	Internal		12 bit	26 count	Surface Mount		120 MHz	Single-Core
Microchip Technology PIC32MK0512GPE064T-E/MR	Brown-out Detect DMA I2S POR Reset WDT	2.2 V	3.6 V	8 bit	4 K	MIPS32® microAptiv™	125 °C	-40 °C	8 bit	512 KB	512 K	64-VFQFN Exposed Pad	FLASH	9 mm	64-QFN	9 mm	8 bit	128 K	32 Bit	Brown Brown-out Detect/Reset DMA I2S out Detect POR Reset WDT	48	Internal	Automotive	12 bit	26 count	Surface Mount	AEC-Q100	80 MHz	Single-Core
Microchip Technology PIC32MK0512GPE064-E/MR	Brown-out Detect DMA I2S POR Reset WDT	2.2 V	3.6 V	8 bit	4 K	MIPS32® microAptiv™	125 °C	-40 °C	8 bit	512 KB	512 K	64-VFQFN Exposed Pad	FLASH	9 mm	64-QFN	9 mm	8 bit	128 K	32 Bit	Brown Brown-out Detect/Reset DMA I2S out Detect POR Reset WDT	48	Internal	Automotive	12 bit	26 count	Surface Mount	AEC-Q100	80 MHz	Single-Core
Microchip Technology PIC32MK0512GPE064-I/MR	Brown-out Detect DMA I2S POR Reset WDT	2.2 V	3.6 V	8 bit	4 K	MIPS32® microAptiv™	85 °C	-40 °C	8 bit	512 KB	512 K	64-VFQFN Exposed Pad	FLASH	9 mm	64-QFN	9 mm	8 bit	128 K	32 Bit	Brown Brown-out Detect/Reset DMA I2S out Detect POR Reset WDT	48	Internal		12 bit	26 count	Surface Mount		120 MHz

Catalog

High Performance 32-Bit MCU with FPU & DSP

Description

**Recommended Alternative Device -** [**PIC32MK0512GPK064**](https://www.microchip.com/en-us/product/PIC32MK0512GPK064) PIC32MK family devices combine 32-Bit, 120Mhz performance with up to 1MB of Flash memory, and a rich peripheral set targeting applications such as motor control, industrial control and Industrial Internet of Things (IIoT) and multi-channel CAN applications. These devices feature 7x 12-Bit ADC's each operating at up to 3.75MSPS, which can be combined and sequenced to provide up to 18MSPS sampling rates!
