ISL54220 Series

Catalog

HIGH-SPEED USB 2.0 (480MBPS) MULTIPLEXER

Part	Number of Channels	-3db Bandwidth	Operating Temperature (Max)	Operating Temperature (Min)	On-State Resistance (Max)	Package Name	Features	Multiplexer Inputs	Demultiplexer Outputs	Voltage - Supply, Single (V+) (Maximum)	Voltage - Supply, Single (V+) (Minimum)	Switch Circuit Type	Package Length	Package Width	Applications	Mounting Type	Package / Case	Supplied Contents	Type	Function	Embedded	Contents	Primary Attributes	Count	Utilized IC / Part	Supply Voltage (Maximum)	Supply Voltage (Minimum)
Renesas Electronics Corporation ISL54220IUZ-T	2	742 MHz	85 °C	-40 °C	8 Ohms	10-MSOP 10-TFSOP	Break-Before-Make USB 2.0	2	1	5.5 V	2.7 V	SPDT	0.118 in	3 mm	USB	Surface Mount
Renesas Electronics Corporation ISL54220IRTZ-T	2	742 MHz	85 °C	-40 °C	8 Ohms	10-TDFN	Break-Before-Make USB 2.0	2	1	5.5 V	2.7 V	SPDT	3 mm	3 mm	USB	Surface Mount	10-VFDFN Exposed Pad
Renesas Electronics Corporation ISL54220IUZ	2	742 MHz	85 °C	-40 °C	8 Ohms	10-MSOP 10-TFSOP	Break-Before-Make USB 2.0	2	1	5.5 V	2.7 V	SPDT	0.118 in	3 mm	USB	Surface Mount
Renesas Electronics Corporation ISL54220IRUZ-T	2	742 MHz	85 °C	-40 °C	8 Ohms	10-UTQFN	Break-Before-Make USB 2.0	2	1	5.5 V	2.7 V	SPDT	1.8 mm	1.4 mm	USB	Surface Mount	10-UFQFN
Renesas Electronics Corporation ISL54220IRUEVAL1Z																		Board(s)	Interface	1 Multiplexer 2	No	Board	2 x SPDT Analog Switch SPDT Analog Switch	2	ISL54220	5.5 V	2.7 V
Renesas Electronics Corporation ISL54220IRTZ	2	742 MHz	85 °C	-40 °C	8 Ohms	10-TDFN	Break-Before-Make USB 2.0	2	1	5.5 V	2.7 V	SPDT	3 mm	3 mm	USB	Surface Mount	10-VFDFN Exposed Pad
