EXB-F10 Series
Manufacturer: Panasonic Electronic Components
Beta
⌘K
RES ARRAY 9 RES 680K OHM 10SIP
| Part | Resistance | Height - Seated (Max) | Size / Dimension Length | Size / Dimension Width | Number of Pins | Temperature Coefficient | Package / Case | Tolerance | Operating Temperature (Max) | Operating Temperature (Min) | Power Per Element | Package Name | Mounting Type | Circuit Type | Number of Resistors |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panasonic Electronic Components | 680 kOhm | 0.195 in | 0.986 in | 0.1 in | 10 | 200 ppm/°C | 10-SIP | 2 % | 125 °C | -55 °C | 125 mW | 10-SIP | Through Hole | Bussed | 9 |
Panasonic Electronic Components | 1.5 kOhms | 0.195 in | 0.986 in | 0.1 in | 10 | 200 ppm/°C | 10-SIP | 2 % | 125 °C | -55 °C | 200 mW | 10-SIP | Through Hole | Isolated | 5 |
 Panasonic Electronic Components | 68 kOhm | 0.195 in | 0.986 in | 0.1 in | 10 | 200 ppm/°C | 10-SIP | 2 % | 125 °C | -55 °C | 125 mW | 10-SIP | Through Hole | Bussed | 9 |
Panasonic Electronic Components | 220 Ohm 270 Ohm | 0.195 in | 0.986 in | 0.1 in | 10 | 200 ppm/°C | 10-SIP | 2 % | 125 °C | -55 °C | 125 mW | 10-SIP | Through Hole | Dual Terminator | 16 |
