078172 Series
Manufacturer: Molex
Beta
⌘K
CONN RCPT HSG 7POS 1.20MM
| Part | Note | Contact Termination | Color | Connector Type | Mounting Type | Insulation Material | Contact Type | Pitch | Operating Temperature (Min) | Operating Temperature (Max) | Number of Rows | Fastening Type | Number of Positions | Wire Gauge (AWG) (Min) | Wire Gauge (AWG) (Max) | Contact Finish Thickness | Pin or Socket | Type | Contact Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Contacts Not Included | Crimp | Black | Receptacle | Free Hanging (In-Line) Right Angle | Nylon 4/6 Polyamide (PA46) | Female Socket | 0.047 in | -40 °C | 105 °C | 1 | Friction Lock | 7 | ||||||
 Molex | Contacts Not Included | Crimp | Black | Receptacle | Free Hanging (In-Line) Right Angle | Liquid Crystal Polymer (LCP) | Female Socket | 0.047 in | -25 °C | 85 °C | 1 | Friction Lock | 4 | ||||||
 Molex | Contacts Not Included | Crimp | Black | Receptacle | Free Hanging (In-Line) Right Angle | Liquid Crystal Polymer (LCP) | Female Socket | 0.047 in | -25 °C | 85 °C | 1 | Friction Lock | 3 | ||||||
 Molex | Contacts Not Included | Crimp | Black | Receptacle | Free Hanging (In-Line) Right Angle | Nylon 4/6 Polyamide (PA46) | Female Socket | 0.047 in | -40 °C | 105 °C | 1 | Friction Lock | 6 | ||||||
 Molex | Crimp | 27.5 AWG | 30 AWG | 3.94 µin | Socket | Stamped | Gold | ||||||||||||
 Molex | Crimp | 27.5 AWG | 30 AWG | 3.94 µin | Socket | Stamped | Gold |
