MCP6C02 Series

Catalog

IC CURRENT SENSE 1 CIRCUIT 8VDFN

Part	Voltage - Input Offset	Mounting Type	Gain Bandwidth Product	Package / Case	Voltage - Supply Span (Min)	Voltage - Supply Span (Max)	Current - Input Bias	Number of Circuits	Operating Temperature (Min)	Operating Temperature (Max)	Current - Supply	Package Width	Package Name	Package Length	Amplifier Type
Microchip Technology MCP6C02T-100H/Q8BVAO	1.5 µV	Surface Mount Wettable Flank	500 kHz	8-VDFN Exposed Pad	2 V	5.5 V	170 µA	1	-40 °C	150 °C	490 µA	3 mm	8-VDFN	3 mm	Current Sense
Microchip Technology MCP6C02T-020E/CHY	1.9 µV	Surface Mount	500 kHz	SOT-23-6	2 V	5.5 V	170 µA	1	-40 °C	125 °C	490 µA		SOT-23-6		Current Sense
Microchip Technology MCP6C02T-020H/Q8BVAO	1.9 µV	Surface Mount Wettable Flank	500 kHz	8-VDFN Exposed Pad	2 V	5.5 V	170 µA	1	-40 °C	150 °C	490 µA	3 mm	8-VDFN	3 mm	Current Sense
Microchip Technology MCP6C02T-020E/CHYVAO	1.9 µV	Surface Mount	500 kHz	SOT-23-6	2 V	5.5 V	170 µA	1	-40 °C	125 °C	490 µA		SOT-23-6		Current Sense
Microchip Technology MCP6C02T-100E/CHY	1.5 µV	Surface Mount	390 kHz	SOT-23-6	2 V	5.5 V	170 µA	1	-40 °C	125 °C	490 µA		SOT-23-6		Current Sense
Microchip Technology MCP6C02T-050H/Q8B	1.65 µV	Surface Mount Wettable Flank	500 kHz	8-VDFN Exposed Pad	2 V	5.5 V	170 µA	1	-40 °C	150 °C	490 µA	3 mm	8-VDFN	3 mm	Current Sense
Microchip Technology MCP6C02T-050E/CHY	1.65 µV	Surface Mount	500 kHz	SOT-23-6	2 V	5.5 V	170 µA	1	-40 °C	125 °C	490 µA		SOT-23-6		Current Sense
Microchip Technology MCP6C02T-050H/Q8BVAO	1.65 µV	Surface Mount Wettable Flank	500 kHz	8-VDFN Exposed Pad	2 V	5.5 V	170 µA	1	-40 °C	150 °C	490 µA	3 mm	8-VDFN	3 mm	Current Sense
Microchip Technology MCP6C02T-100E/CHYVAO	1.5 µV	Surface Mount	500 kHz	SOT-23-6	2 V	5.5 V	170 µA	1	-40 °C	125 °C	490 µA		SOT-23-6		Current Sense
