053325 Series
Manufacturer: Molex
Beta
⌘K
CONN HEADER R/A 2POS 2MM
| Part | Contact Type | Contact Length - Mating | Style | Mounting Type | Material Flammability Rating | Contact Finish - Post | Number of Positions | Insulation Material | Contact Length - Post | Termination | Number of Positions Loaded | Pitch - Mating | Shrouding | Fastening Type | Contact Shape | Contact Material | Number of Rows | Contact Finish - Mating | Insulation Height | Insulation Color | Connector Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Male Pin | 0.136 in | Board Cable/Wire | Right Angle Through Hole | UL94 V-0 | Tin | 2 | Glass Filled Polybutylene Terephthalate (PBT) | 0.138 in | Kinked Pin Solder | All | 0.079 in | Shrouded - 4 Wall | Detent Lock | Square | Brass | 1 | Tin | 0.191 in | Natural | Header |
 Molex | Male Pin | 0.136 in | Board Cable/Wire | Right Angle Through Hole | UL94 V-0 | Tin | 8 | Glass Filled Polybutylene Terephthalate (PBT) | 0.138 in | Kinked Pin Solder | All | 0.079 in | Shrouded - 4 Wall | Detent Lock | Square | Brass | 1 | Tin | 0.191 in | Natural | Header |
Molex | Male Pin | 0.136 in | Board Cable/Wire | Right Angle Through Hole | UL94 V-0 | Tin | 12 | Glass Filled Polybutylene Terephthalate (PBT) | 0.138 in | Kinked Pin Solder | All | 0.079 in | Shrouded - 4 Wall | Detent Lock | Square | Brass | 1 | Tin | 0.191 in | Natural | Header |
 Molex | Male Pin | 0.136 in | Board Cable/Wire | Right Angle Through Hole | UL94 V-0 | Tin | 15 | Glass Filled Polybutylene Terephthalate (PBT) | 0.138 in | Kinked Pin Solder | All | 0.079 in | Shrouded - 4 Wall | Detent Lock | Square | Brass | 1 | Tin | 0.191 in | Natural | Header |
 Molex | Male Pin | 0.136 in | Board Cable/Wire | Right Angle Through Hole | UL94 V-0 | Tin | 4 | Glass Filled Polybutylene Terephthalate (PBT) | 0.138 in | Kinked Pin Solder | All | 0.079 in | Shrouded - 4 Wall | Detent Lock | Square | Brass | 1 | Tin | 0.191 in | Natural | Header |
 Molex | Male Pin | 0.136 in | Board Cable/Wire | Right Angle Through Hole | UL94 V-0 | Tin | 13 | Glass Filled Polybutylene Terephthalate (PBT) | 0.138 in | Kinked Pin Solder | All | 0.079 in | Shrouded - 4 Wall | Detent Lock | Square | Brass | 1 | Tin | 0.191 in | Natural | Header |
