PTC 16V POLYFUSE SURF MOUNT 2920 5.00A
Description
AI
The 2920L Series PTC provides surface mount overcurrent protection for medium voltage (≤60V) applications where resettable protection is desired.
Beta
⌘K
PTC 16V POLYFUSE SURF MOUNT 2920 5.00A
PTC 16V POLYFUSE SURF MOUNT 2920 5.00A
| Part | Current - Max | Size / Dimension Length | Size / Dimension Width | Package / Case | Time to Trip | Resistance - Initial (Ri) (Min) | Resistance - Post Trip (R1) (Max) | Operating Temperature (Min) | Operating Temperature (Max) | Current - Trip (It) | Type | Voltage - Max | Thickness (Max) | Current - Hold (Ih) (Max) | Mounting Type | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 LITTELFUSE | 40 A | 0.289 in | 0.202 in | 2920 (7351 Metric) Concave | 5 s | 5 mOhms | 25 mOhms | -40 °C | 85 °C | 10 A | Polymeric | 16 V | 0.063 in | 5 A | Surface Mount | cURus TUV |
