72T36135M Series

Catalog

IC FIFO ASYN/SYN 512KX36 240BGA

Part	Memory Depth	Memory Width	Memory Size (Total)	Expansion Type	Mounting Type	Current - Supply (Max)	Programmable Flags Support	Operating Temperature (Min)	Operating Temperature (Max)	Function	Package Name	Package Length	Package Width	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Access Time (Value 2)	Access Time (Value 1)	Retransmit Capability	Package / Case	Data Rate	Data Rate	FWFT Support	Bus Directional
Renesas Electronics Corporation 72T36135ML6BBI	512 K	36 bit	18 M	Depth Width	Surface Mount	180 mA	Yes	-40 °C	85 °C	Asynchronous Synchronous	240-PBGA	19 mm	19 mm	2.375 V	2.625 V	3.8 ns	12 ns	Yes	240-BGA	166MHz 66MHz	66 MHz 166 MHz	Yes	Uni-Directional
Renesas Electronics Corporation 72T36135ML5BBG	512 K	36 bit	18 M	Depth Width	Surface Mount	180 mA	Yes	0 °C	70 °C	Asynchronous Synchronous	240-PBGA	19 mm	19 mm	2.375 V	2.625 V	3.6 ns	10 ns	Yes	240-BGA	200MHz 83MHz	83 MHz 200 MHz	Yes	Uni-Directional
Renesas Electronics Corporation 72T36135ML5BB	512 K	36 bit	18 M	Depth Width	Surface Mount	180 mA	Yes	0 °C	70 °C	Asynchronous Synchronous	240-PBGA	19 mm	19 mm	2.375 V	2.625 V	3.6 ns	10 ns	Yes	240-BGA	200MHz 83MHz	83 MHz 200 MHz	Yes	Uni-Directional
Renesas Electronics Corporation 72T36135ML6BB	512 K	36 bit	18 M	Depth Width	Surface Mount	180 mA	Yes	0 °C	70 °C	Asynchronous Synchronous	240-PBGA	19 mm	19 mm	2.375 V	2.625 V	3.8 ns	12 ns	Yes	240-BGA	166MHz 66MHz	66 MHz 166 MHz	Yes	Uni-Directional
