PIC12CE519 Series | Microchip Technology | Zenode.ai

Catalog

IC MCU 8BIT 1.5KB OTP 8SOIJ

Part	Voltage - Supply (Vcc/Vdd) Minimum	Voltage - Supply (Vcc/Vdd) Maximum	Speed	Operating Temperature (Max)	Operating Temperature (Min)	Number of I/O	Core Size (Bit Width)	EEPROM Size (Depth)	EEPROM Size (Width)	Oscillator Type	Package Length	Package Name	Package Width	RAM Size Width	RAM Size Depth	Program Memory Type	Core Processor	Program Memory Size	Program Memory Width	Program Memory Depth	Mounting Type	Peripherals	Package Features
Microchip Technology PIC12CE519T-04E/SM	3 V	5.5 V	4 MHz	125 °C	-40 °C	5	8 Bit	16	8 bit	Internal	0.209 in	8-SOIC 8-SOIJ	5.3 mm	8 bit	41	OTP	PIC	1.5 KB	12	1 K	Surface Mount	POR WDT
Microchip Technology PIC12CE519-04/P	3 V	5.5 V	4 MHz	70 °C	0 °C	5	8 Bit	16	8 bit	Internal	0.3 in	8-DIP 8-PDIP	7.62 mm	8 bit	41	OTP	PIC	1.5 KB	12	1 K	Through Hole	POR WDT
Microchip Technology PIC12CE519-04/SM	3 V	5.5 V	4 MHz	70 °C	0 °C	5	8 Bit	16	8 bit	Internal	0.209 in	8-SOIC 8-SOIJ	5.3 mm	8 bit	41	OTP	PIC	1.5 KB	12	1 K	Surface Mount	POR WDT
Microchip Technology PIC12CE519T-04E/SN	3 V	5.5 V	4 MHz	125 °C	-40 °C	5	8 Bit	16	8 bit	Internal	0.154 in	8-SOIC	3.9 mm	8 bit	41	OTP	PIC	1.5 KB	12	1 K	Surface Mount	POR WDT
Microchip Technology PIC12CE519-04I/SN	3 V	5.5 V	4 MHz	85 °C	-40 °C	5	8 Bit	16	8 bit	Internal	0.154 in	8-SOIC	3.9 mm	8 bit	41	OTP	PIC	1.5 KB	12	1 K	Surface Mount	POR WDT
Microchip Technology PIC12CE519-04I/P	3 V	5.5 V	4 MHz	85 °C	-40 °C	5	8 Bit	16	8 bit	Internal	0.3 in	8-DIP 8-PDIP	7.62 mm	8 bit	41	OTP	PIC	1.5 KB	12	1 K	Through Hole	POR WDT
Microchip Technology PIC12CE519-04E/SM	3 V	5.5 V	4 MHz	125 °C	-40 °C	5	8 Bit	16	8 bit	Internal	0.209 in	8-SOIC 8-SOIJ	5.3 mm	8 bit	41	OTP	PIC	1.5 KB	12	1 K	Surface Mount	POR WDT
Microchip Technology PIC12CE519-04I/SM	3 V	5.5 V	4 MHz	85 °C	-40 °C	5	8 Bit	16	8 bit	Internal	0.209 in	8-SOIC 8-SOIJ	5.3 mm	8 bit	41	OTP	PIC	1.5 KB	12	1 K	Surface Mount	POR WDT
Microchip Technology PIC12CE519-04/SN	3 V	5.5 V	4 MHz	70 °C	0 °C	5	8 Bit	16	8 bit	Internal	0.154 in	8-SOIC	3.9 mm	8 bit	41	OTP	PIC	1.5 KB	12	1 K	Surface Mount	POR WDT
Microchip Technology PIC12CE519/JW	3 V	5.5 V	4 MHz	70 °C	0 °C	5	8 Bit	16	8 bit	Internal	0.3 in	8-CDIP	7.62 mm	8 bit	41	EPROM UV	PIC	1.5 KB	12	1 K	Through Hole	POR WDT	Window
