098817 Series
Manufacturer: Molex
Beta
⌘K
CONN RCPT HSG 3POS BLK
| Part | Note | Connector Type | Number of Rows | Number of Positions | Contact Termination | Fastening Type | Color | Contact Type | Mounting Type | Insulation Material | Operating Temperature (Min) | Operating Temperature (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Contacts Not Included | Receptacle | 1 | 3 | Crimp | Latch Holder | Black | Female Socket | Free Hanging (In-Line) | Polybutylene Terephthalate (PBT) Polyester | -40 °C | 85 °C |
 Molex | Contacts Not Included | Receptacle | 1 | 2 | Crimp | Latch Holder | Black | Female Socket | Free Hanging (In-Line) | Polybutylene Terephthalate (PBT) Polyester | -40 °C | 85 °C |
 Molex | Contacts Not Included | Receptacle | 1 | 2 | Crimp | Latch Holder | White | Female Socket | Free Hanging (In-Line) | Polybutylene Terephthalate (PBT) Polyester | -40 °C | 85 °C |
 Molex | Contacts Not Included | Receptacle | 1 | 4 | Crimp | Latch Holder | Green | Female Socket | Free Hanging (In-Line) | Polybutylene Terephthalate (PBT) Polyester | -40 °C | 85 °C |
 Molex | Contacts Not Included | Receptacle | 1 | 3 | Crimp | Latch Holder | Green | Female Socket | Free Hanging (In-Line) | Polybutylene Terephthalate (PBT) Polyester | -40 °C | 85 °C |
 Molex | Contacts Not Included | Receptacle | 1 | 3 | Crimp | Latch Holder | White | Female Socket | Free Hanging (In-Line) | Polybutylene Terephthalate (PBT) Polyester | -40 °C | 85 °C |
 Molex | Contacts Not Included | Receptacle | 1 | 4 | Crimp | Latch Holder | Black | Female Socket | Free Hanging (In-Line) | Polybutylene Terephthalate (PBT) Polyester | -40 °C | 85 °C |
 Molex | Contacts Not Included | Receptacle | 1 | 4 | Crimp | Latch Holder | Gray | Female Socket | Free Hanging (In-Line) | Polybutylene Terephthalate (PBT) Polyester | -40 °C | 85 °C |
