ACTS240MS Series

CMOS Octal Buffer/Line Driver, Three-State, Inverting

Manufacturer: Renesas Electronics Corporation

Catalog

CMOS Octal Buffer/Line Driver, Three-State, Inverting

Part	Mounting Type	Output Type	Package Name	Number of Elements	Package / Case	Logic Type	Number of Bits per Element	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Package Length	Package Width
Renesas Electronics Corporation ACTS240KMSR	Surface Mount	3-State	20-CFlatPack	2	20-CFlatPack	Buffer Driver	4 bits	125 °C	-55 °C	5.5 V	4.5 V
Renesas Electronics Corporation ACTS240DMSR	Through Hole	3-State	20-CDIP 20-SBDIP	2		Buffer Inverting	4 bits	125 °C	-55 °C	5.5 V	4.5 V	0.3 in	7.62 mm

Catalog

CMOS Octal Buffer/Line Driver, Three-State, Inverting

Description

The Intersil ACTS240MS is a radiation hardened high reliability, high-speed CMOS/SOS that has two active low enable inputs. The ACTS240MS utilizes advanced CMOS/SOS technology to achieve high-speed operation. This device is a member of the radiation hardened, high-speed, CMOS/SOS logic family. The ACTS240MS is supplied in a 20-lead ceramic flatpack (K suffix) or a dual in-line ceramic package (D suffix).
