F1385 Series

DPD Demodulator - 3200MHz to 4400MHz

Manufacturer: Renesas Electronics Corporation

Catalog

DPD Demodulator - 3200MHz to 4400MHz

Part	Current - Supply	Package Length	Package Name	Package Width	RF Frequency (Max)	RF Frequency (Min)	Mounting Type	Gain	LO Frequency (Min)	LO Frequency (Max)	Package / Case	P1dB	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Noise Figure	Function
Renesas Electronics Corporation F1385NBGI	210 mA	6 mm	36-VFQFPN	6 mm	4.4 GHz	3.2 GHz	Surface Mount	20 dB	2.85 GHz	4.05 GHz	36-WFQFN Exposed Pad	0 dBm	5.25 V	4.75 V	20 dB	Demodulator

Catalog

DPD Demodulator - 3200MHz to 4400MHz

Description

The F1385 is a Digital Pre-Distortion Demodulator for PA linearization typically used in base stations to significantly improve the ACLR and/or power consumption of the full TX system in base stations transmitter applications.
