74FCT163244 Series

Manufacturer: Renesas Electronics Corporation

Catalog

BUFFERS & LINE DRIVERS 3.3V 16-BIT BUFFER/ LINE DRIVE

Part	Output Type	Logic Type	Number of Elements	Operating Temperature (Max)	Operating Temperature (Min)	Package Length	Package Name	Package Width	Mounting Type	Current - Output Low	Current - Output High	Number of Bits per Element	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)
Renesas Electronics Corporation 74FCT163244CPVG	3-State	Buffer Non-Inverting	4	85 °C	-40 °C	0.295 in	48-BSSOP 48-SSOP	7.5 mm	Surface Mount	24 mA	8 mA	4 bits	3.6 V	2.7 V
Renesas Electronics Corporation 74FCT163244APVG8	3-State	Buffer Non-Inverting	4	85 °C	-40 °C	0.295 in	48-BSSOP 48-SSOP	7.5 mm	Surface Mount	24 mA	8 mA	4 bits	3.6 V	2.7 V
Renesas Electronics Corporation 74FCT163244APAG8	3-State	Buffer Non-Inverting	4	85 °C	-40 °C	0.24 in	48-TFSOP 48-TSSOP	6.1 mm	Surface Mount	24 mA	8 mA	4 bits	3.6 V	2.7 V
Renesas Electronics Corporation 74FCT163244CPFG	3-State	Buffer Non-Inverting	4	85 °C	-40 °C	0.173 in	48-TFSOP 48-TVSOP	4.4 mm	Surface Mount	24 mA	8 mA	4 bits	3.6 V	2.7 V
Renesas Electronics Corporation 74FCT163244CPVG8	3-State	Buffer Non-Inverting	4	85 °C	-40 °C	0.295 in	48-BSSOP 48-SSOP	7.5 mm	Surface Mount	24 mA	8 mA	4 bits	3.6 V	2.7 V
Renesas Electronics Corporation 74FCT163244CPFG8	3-State	Buffer Non-Inverting	4	85 °C	-40 °C	0.173 in	48-TFSOP 48-TVSOP	4.4 mm	Surface Mount	24 mA	8 mA	4 bits	3.6 V	2.7 V
Renesas Electronics Corporation 74FCT163244APFG	3-State	Buffer Non-Inverting	4	85 °C	-40 °C	0.173 in	48-TFSOP 48-TVSOP	4.4 mm	Surface Mount	24 mA	8 mA	4 bits	3.6 V	2.7 V
Renesas Electronics Corporation 74FCT163244APFG8	3-State	Buffer Non-Inverting	4	85 °C	-40 °C	0.173 in	48-TFSOP 48-TVSOP	4.4 mm	Surface Mount	24 mA	8 mA	4 bits	3.6 V	2.7 V
Renesas Electronics Corporation 74FCT163244APAG	3-State	Buffer Non-Inverting	4	85 °C	-40 °C	0.24 in	48-TFSOP 48-TSSOP	6.1 mm	Surface Mount	24 mA	8 mA	4 bits	3.6 V	2.7 V
Renesas Electronics Corporation 74FCT163244CPAG8	3-State	Buffer Non-Inverting	4	85 °C	-40 °C	0.24 in	48-TFSOP 48-TSSOP	6.1 mm	Surface Mount	24 mA	8 mA	4 bits	3.6 V	2.7 V
