ENW-89 Series
Manufacturer: Panasonic Electronic Components
Beta
⌘K
CLASS 1/CLASS 2 BLUETOOTH® V4.0 MODULE, 2.4GHZ - 2.48GHZ, 1.7V - 4.8V
| Part | Current - Transmitting | Sensitivity | Operating Temperature (Min) | Operating Temperature (Max) | RF Family/Standard | Modulation | Antenna Type | Mounting Type | Utilized IC / Part | Protocol | Package / Case | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Data Rate | Current - Receiving | Power - Output | Serial Interfaces | Frequency | Memory Type | Memory Size (SRAM) | Memory Size (Flash) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panasonic Electronic Components | 33 mA | -93 dBm | -40 °C | 85 °C | Bluetooth | GFSK | Antenna Not Included | Surface Mount | CC2564 | Bluetooth v4.0 | Module | 4.8 V | 1.7 V | 3 Mbps | 33 mA | 10 dBm | I2S UART | 2.4 GHz | |||
 Panasonic Electronic Components | -93 dBm | -20 °C | 70 °C | Bluetooth | DPSK DQPSK GFSK GMSK | Antenna Not Included | Surface Mount | Si1000 | Bluetooth v2.1 +EDR Class 2 | PCB Module | 4.8 V | 1.7 V | 2.18 Mbps | 10.5 dBm | I2C SPI UART | 2.4 GHz | |||||
 Panasonic Electronic Components | 33 mA | -93 dBm | -20 °C | 70 °C | Bluetooth | GFSK | Chip Integrated | Surface Mount | ESP32 | Bluetooth v4.0 | Module | 4.8 V | 1.7 V | 3 Mbps | 33 mA | 10 dBm | I2S UART | 2.4 GHz | |||
 Panasonic Electronic Components | 33 mA | -93 dBm | -20 °C | 70 °C | Bluetooth | GFSK | Antenna Not Included | Surface Mount | CC2567 | Bluetooth v4.0 | PCB Module | 4.8 V | 1.7 V | 3 Mbps | 33 mA | 10 dBm | I2S UART | 2.4 GHz | |||
 Panasonic Electronic Components | 33 mA | -93 dBm | -40 °C | 85 °C | Bluetooth | GFSK | Chip Integrated | Surface Mount | CC2564B | Bluetooth v4.0 | Module | 4.8 V | 1.7 V | 3 Mbps | 33 mA | 10 dBm | I2S UART | 2.4 GHz | |||
 Panasonic Electronic Components | 40 mA | -93 dBm | -40 °C | 85 °C | Bluetooth | GFSK | Antenna Not Included | Surface Mount | Si1000 | Bluetooth v2.1 +EDR | Module | 4.8 V | 1.7 V | 3 Mbps | 40 mA | 10.5 dBm | I2S UART | 2.4 GHz | |||
Panasonic Electronic Components | 33 mA | -93 dBm | -40 °C | 85 °C | Bluetooth | GFSK | Antenna Not Included | Surface Mount | Bluetooth v4.0 | Module | 4.8 V | 1.7 V | 3 Mbps | 33 mA | 10 dBm | I2S UART | 2.4 GHz | ||||
 Panasonic Electronic Components | 14.3 mA | -93 dBm | -40 °C | 85 °C | Bluetooth | Chip Integrated | Surface Mount | CC2541 | Bluetooth v4.0 | Module | 3.6 V | 2 V | 10 kbps | 0 dBm | I2C SPI UART | 2.4 GHz | Flash SRAM | 8 kB | 256 KB | ||
 Panasonic Electronic Components | 33 mA | -93 dBm | -40 °C | 85 °C | Bluetooth | GFSK | Chip Integrated | Surface Mount | CC2567 | Bluetooth v4.0 | Module | 4.8 V | 1.7 V | 3 Mbps | 33 mA | 10 dBm | I2S UART | 2.4 GHz | |||
 Panasonic Electronic Components | 4.9 mA | -93 dBm | -40 °C | 85 °C | Bluetooth | Chip Integrated | Surface Mount | Bluetooth v4.0 Dual Mode | Module | 3.3 V | 2.35 V | 4.9 mA | 0 dBm | 2.4 GHz |
