IXFH98N60X3 Series

Discrete MOSFET 98A 600V X3 TO247

Catalog

Discrete MOSFET 98A 600V X3 TO247

Part	Drain to Source Voltage (Vdss)	Rds On (Max)	Package / Case	Vgs(th) (Max)	Vgs (Max)	Technology	FET Type	Operating Temperature (Min)	Operating Temperature (Max)	Mounting Type	Package Name	Input Capacitance (Ciss) (Max)	Current - Continuous Drain (Id) (Tc)	Power Dissipation (Max)	Gate Charge (Max)	Drive Voltage (Max Rds On, Min Rds On)
LITTELFUSE IXFH98N60X3	600 V	30 mOhm	TO-247-3	5 V	20 V	MOSFET (Metal Oxide)	N-Channel	-55 °C	150 °C	Through Hole	TO-247 (IXTH)	6250 pF	98 A	960 W	90 nC	10 V

Catalog

Discrete MOSFET 98A 600V X3 TO247

Description

The 600V X3-Class Ultra Junction MOSFET IXFH98N60X3 is available in 98A nominal current rating and TO-247 package. These Power MOSFETs feature significantly reduced channel resistance RDS(on) and gate charge Qg. They feature the lowest figures of merit (FOM) RDS(on)xQg and RDS(on)xRthJC. These benefits enable designers to achieve higher efficiency using simplified thermal design. This HiPerFET™ series of power MOSFETs feature body diodes which offer low reverse recovery charge (QRM) and short reverse recovery time (trr).
