INDUCTIVE PROXIMITY SENSOR, 5 MM, CYLINDRICAL, PNP, 10 TO 30 VDC, CONNECTOR
| Part | Material - Body | Shielding | Sensor Type | Output Type | Termination Style | Package / Case | Ingress Protection | Sensing Distance | Operating Temperature (Max) | Operating Temperature (Min) | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) | Indicator | Voltage - Supply (Range 2 Maximum) | Voltage - Supply (Range 1 Minimum) | Voltage - Supply (Range 1 Maximum) | Voltage - Supply (Range 2 Minimum) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Pepperl+Fuchs, Inc. | Stainless Steel | Unshielded | Inductive | 3-Wire PNP-NO | Connector | Cylinder Threaded - M18 | IP67 IP68 IP69K | 0.197 " | 70 °C | -25 °C | 10 VDC | 30 VDC | LED | ||||
 Pepperl+Fuchs, Inc. | Stainless Steel | Unshielded | Inductive | 2-Wire SCR-NO | Connector | Cylinder Threaded - M18 | IP67 | 0.197 " | 70 °C | -25 °C | LED | 300 VDC | 20 VAC | 250 VAC | 20 VDC | ||
 Pepperl+Fuchs, Inc. | Stainless Steel | Unshielded | Inductive | 3-Wire PNP-NO | Connector | Cylinder Threaded - M18 | IP67 IP68 IP69K | 0.197 " | 70 °C | -40 °C | 10 VDC | 30 VDC | LED | ||||
 Pepperl+Fuchs, Inc. | Stainless Steel | Unshielded | Inductive | 2-Wire SCR-NO | Cable with Connector | Cylinder Threaded - M18 | IP67 IP68 IP69K | 0.197 " | 70 °C | -25 °C | 6 V | 30 VDC | LED | ||||
 Pepperl+Fuchs, Inc. | Stainless Steel | Unshielded | Inductive | 2-Wire SCR-NO | Connector | Cylinder Threaded - M18 | IP67 | 0.197 " | 70 °C | -25 °C | LED | 300 VDC | 20 VAC | 250 VAC | 20 VDC |
