KD22 Series

Catalog

CONNECTOR: PLUGGABLE TERMINAL BLOCK; PLUG; FEMALE; 12A; 300V; 1X22

Part	Plug Wire Entry Angle	Features	Operating Temperature (Min)	Operating Temperature (Max)	Mounting Type	Pitch	Number of Positions	Positions Per Level	Voltage - UL	Number of Levels	Type	Wire Gauge or Range - AWG (Max)	Wire Gauge or Range - AWG (Min)	Contact Mating Finish	Color	Termination Style	Current - UL	Wire Strip Length (Min)	Wire Strip Length (Max)	Contact Material	Material Flammability Rating	Insulation Height	Housing Material
McGill Microwave Systems KD2250520000G	180 °	Latch Lock	-40 °C	115 °C	Free Hanging (In-Line)	5.08 mm	22	22	300 V	1	Female Sockets Plug	24 AWG	14 AWG	Tin	Green	Push-In Spring Screwless - Leg Spring	12 A	11 mm	12 mm	Phosphor Bronze	UL94 V-0	0.429 in	Thermoplastic
McGill Microwave Systems KD2270520000G	180 °	Latch Lock Retention Latches (Wire Side)	-40 °C	115 °C	Free Hanging (In-Line)	0.197 in	22	22	300 V	1	Female Sockets Plug	24 AWG	14 AWG	Tin	Green	Push-In Spring Screwless - Leg Spring	12 A	11 mm	12 mm	Phosphor Bronze	UL94 V-0	0.429 in	Thermoplastic
McGill Microwave Systems KD2210520000G	180 °	Latch Lock	-40 °C	115 °C	Free Hanging (In-Line)	0.138 in	22	22	160 V	1	Female Sockets Plug	24 AWG	16 AWG	Tin	Green	Push-In Spring Screwless - Leg Spring	5.5 A	9 mm	10 mm	Phosphor Bronze	UL94 V-0	0.307 in	Thermoplastic
McGill Microwave Systems KD2270510000G	180 °	Mating Flange Retention Latches (Wire Side)	-40 °C	115 °C	Free Hanging (In-Line)	0.197 in	22	22	300 V	1	Female Sockets Plug	24 AWG	14 AWG	Tin	Green	Push-In Spring Screwless - Leg Spring	12 A	11 mm	12 mm	Phosphor Bronze	UL94 V-0	0.429 in	Thermoplastic
McGill Microwave Systems KD2210500000G	180 °		-40 °C	115 °C	Free Hanging (In-Line)	0.138 in	22	22	160 V	1	Female Sockets Plug	24 AWG	16 AWG	Tin	Green	Push-In Spring Screwless - Leg Spring	5.5 A	9 mm	10 mm	Phosphor Bronze	UL94 V-0	0.307 in	Thermoplastic
McGill Microwave Systems KD2230510000G	180 °	Mating Flange	-40 °C	115 °C	Free Hanging (In-Line)	0.15 in	22	22	300 V	1	Female Sockets Plug	24 AWG	16 AWG	Tin	Green	Push-In Spring Screwless - Leg Spring	5.5 A	9 mm	10 mm	Phosphor Bronze	UL94 V-0	0.307 in	Thermoplastic
McGill Microwave Systems KD2210510000G	180 °	Mating Flange	-40 °C	115 °C	Free Hanging (In-Line)	0.138 in	22	22	160 V	1	Female Sockets Plug	24 AWG	16 AWG	Tin	Green	Push-In Spring Screwless - Leg Spring	5.5 A	9 mm	10 mm	Phosphor Bronze	UL94 V-0	0.307 in	Thermoplastic
