ADL6331 Series

0.38 GHz to 15 GHz TxVGA

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

0.38 GHz to 15 GHz TxVGA

Part	P1dB	RF Type	Package Width	Package Name	Package Length	Test Frequency	Gain	Frequency (Max)	Frequency (Min)	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Mounting Type	Noise Figure	Package / Case	Current - Supply
Analog Devices Inc./Maxim Integrated ADL6331ACCZA	13 dBm	General Purpose	4 mm	24-LGA	4 mm	2 GHz	14.4 dB	8 GHz	380 MHz	3.135 V	3.465 V	Surface Mount	7.5 dB	24-VFLGA Exposed Pad
Analog Devices Inc./Maxim Integrated ADL6331ACCZB-R7	13 dBm	General Purpose	4 mm	24-LGA	4 mm	2 GHz	14.8 dB	8 GHz 15 GHz	1 GHz 380 MHz	3.135 V	3.465 V	Surface Mount	25.3 dB	24-VFLGA Exposed Pad	160 mA
Analog Devices Inc./Maxim Integrated ADL6331ACCZA-R7	13 dBm	General Purpose	4 mm	24-LGA	4 mm	2 GHz	14.4 dB	8 GHz	380 MHz	3.135 V	3.465 V	Surface Mount	7.5 dB	24-VFLGA Exposed Pad
Analog Devices Inc./Maxim Integrated ADL6331ACCZB	13 dBm 37.8 dBm	General Purpose	4 mm	24-LGA	4 mm	2 GHz 8 GHz	14.4 dB	8 GHz 15 GHz	1 GHz 380 MHz	3.135 V	3.465 V	Surface Mount	7.5 dB	24-VFLGA Exposed Pad	160 mA

Catalog

0.38 GHz to 15 GHz TxVGA

Description

The ADL6331 transmit variable gain amplifier (TxVGA) provides an interface from RF digital-to-analog converters (RF DACs) to a singled-ended power amplifier (PA) signal chain. Each ADL6331 IC is composed of a balun, two differential RF amplifiers with bypass attenuators, and a digital step attenuator (DSA) to provide suitable transmitter performance in a 24-terminal, 4.0 mm x 4.0 mm LGA package.Serial-port interface (SPI) control is available to configure RF signal paths or to optimize supply current vs. performance.An integrated RF balun is used to provide a single-ended output over 0.38 GHz to 8.0 GHz (ADL6331-A) or 1.0 GHz to 15.0 GHz (ADL6331-B) with good impedance match.ApplicationsAerospace and defenseInstrumentation and test equipmentCommunication systems
