1211-40 Series
Manufacturer: McGill Microwave Systems
Beta
⌘K
SMP MALE PCB SURFACE MOUNT CONNE
| Part | Body Finish | Body Material | Mating Cycles | Center Contact Plating | Operating Temperature (Min) | Operating Temperature (Max) | Dielectric Material | Shield Termination | Center Contact Material | Mounting Type | Frequency - Max | Number of Ports | Contact Termination | Impedance | Housing Color | Connector Style | Features | Fastening Type | Connector Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 McGill Microwave Systems | Gold | Beryllium Copper | 1000 cycles | Gold | -65 °C | 165 °C | Polyamide-Imide (PAI) | Solder | Beryllium Copper | Surface Mount | 25 GHz | 1 | Solder | 50 Ohm | Gold | SMP | Pre-Tinned (J-STD-001) Smooth Bore | Snap-On | Male Pin Plug |
 McGill Microwave Systems | Gold | Beryllium Copper | 100 cycles | Gold | -55 °C | 125 °C | Polytetrafluoroethylene (PTFE) | Solder | Beryllium Copper | Through Hole | 26.5 GHz | 1 | Solder | 50 Ohm | Gold | SMP | Full Detent Pre-Tinned (J-STD-001) | Snap-On | Male Pin Plug |
 McGill Microwave Systems | Gold | Beryllium Copper | 1000 cycles | Gold | Polyamide-Imide (PAI) | Solder | Beryllium Copper | Surface Mount | 26.5 GHz | 1 | Solder | 50 Ohm | Gold | SMP | Smooth Bore | Snap-On | Male Pin Plug | ||
 McGill Microwave Systems | Gold | Beryllium Copper | 100 cycles | Gold | -65 °C | 165 °C | Polyamide-Imide (PAI) | Solder | Beryllium Copper | Surface Mount Through Hole | 26.5 GHz | 1 | Solder | 50 Ohm | Gold | SMP | Full Detent | Snap-On | Male Pin Plug |
 McGill Microwave Systems | Gold | Beryllium Copper | 500 cycles | Gold | -55 °C | 125 °C | Polyamide-Imide (PAI) | Solder | Beryllium Copper | Surface Mount | 26.5 GHz | 1 | Solder | 50 Ohm | Gold | SMP | Limited Detent | Snap-On | Male Pin Plug |
 McGill Microwave Systems | Gold | Beryllium Copper | 1000 cycles | Gold | -65 °C | 165 °C | Polyamide-Imide (PAI) | Solder | Beryllium Copper | Surface Mount Through Hole | 25 GHz | 1 | Solder | 50 Ohm | Gold | SMP | Pre-Tinned (J-STD-001) Smooth Bore | Snap-On | Male Pin Plug |
 McGill Microwave Systems | Gold | Beryllium Copper | 100 cycles | Gold | -65 °C | 165 °C | Polyamide-Imide (PAI) | Solder | Beryllium Copper | Surface Mount Through Hole | 25 GHz | 1 | Solder | 50 Ohm | Gold | SMP | Full Detent Pre-Tinned (J-STD-001) | Snap-On | Male Pin Plug |
 McGill Microwave Systems | Gold | Beryllium Copper | Gold | -55 °C | 125 °C | Polyamide-Imide (PAI) | Solder | Beryllium Copper | Surface Mount | 26.5 GHz | 1 | Solder | 50 Ohm | Gold | SMP | Full Detent | Snap-On | Male Pin Plug | |
 McGill Microwave Systems | Gold | Beryllium Copper | 100 cycles | Gold | -55 °C | 125 °C | Polytetrafluoroethylene (PTFE) | Solder | Beryllium Copper | Through Hole | 26.5 GHz | 1 | Solder | 50 Ohm | Gold | SMP | Full Detent | Snap-On | Male Pin Plug |
 McGill Microwave Systems | Gold | Beryllium Copper | 100 cycles | Gold | -65 °C | 165 °C | Polyamide-Imide (PAI) | Solder | Beryllium Copper | Surface Mount | 25 GHz | 1 | Solder | 50 Ohm | Gold | SMP | Full Detent Pre-Tinned (J-STD-001) | Snap-On | Male Pin Plug |
