AD7985 Series

Catalog

16-BIT, 2.5 MSPS PULSAR 11 MW ADC IN QFN

Part	Data Interface	Voltage - Supply, Analog (Min)	Voltage - Supply, Analog (Max)	Architecture	Ratio - ADC	Ratio - S/H	Input Type	Number of Inputs	Mounting Type	Package / Case	Number of Bits	Package Length	Package Name	Package Width	Sampling Rate (Per Second)	Configuration	Operating Temperature (Min)	Operating Temperature (Max)	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Reference Type	Number of A/D Converters
Analog Devices Inc./Maxim Integrated AD7985BCPZ	DSP SPI	2.375 V	2.625 V	SAR	1	1	Pseudo-Differential	1	Surface Mount	20-WFQFN Exposed Pad CSP	16 bits	4 mm	20-LFCSP	4 mm	2.5 MHz	S/H-ADC	-40 °C	85 °C	2.375 V	2.625 V	External Internal	1 count
Analog Devices Inc./Maxim Integrated AD7985BCPZ-RL7	DSP SPI	2.375 V	2.625 V	SAR	1	1	Pseudo-Differential	1	Surface Mount	20-WFQFN Exposed Pad CSP	16 bits	4 mm	20-LFCSP	4 mm	2.5 MHz	S/H-ADC	-40 °C	85 °C	2.375 V	2.625 V	External Internal	1 count
