ADL8142-2 Series

For more information on the ADL8142-2C-CSL, please refer to the corresponding data sheet.ADL8142-2CHIPThe ADL8142-2CHIP is a gallium arsenide (GaAs), monolithic microwave integrated circuit (MMIC), pseudomorphic high electron mobility transistor (pHEMT), low noise wideband amplifier that operates from 23 GHz to 31 GHz. The ADL8142-2CHIP provides a typical gain of 26.5 dB, a 1.8 dB typical noise figure, and a typical output third-order intercept (OIP3) of 20 dBm at 27 GHz to 31 GHz, requiring only 25 mA from a 2 V supply voltage. Note that the OIP3 can be improved with larger drain currents. The ADL8142-2CHIP also features inputs and outputs that are ac-coupled and internally matched to 50 Ω, making it ideal for high capacity microwave radio applications.APPLICATIONSSatellite communicationTelecommunicationsCivilian radar
