ADM823 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

IC SUPERVISOR W/RESET SC70-5

Part	Operating Temperature (Max)	Operating Temperature (Min)	Package / Case	Reset Timeout (Minimum)	Voltage - Threshold	Reset	Number of Voltages Monitored	Package Name	Type	Mounting Type	Output
Analog Devices Inc./Maxim Integrated ADM823RYKS-R7	125 °C	-40 °C	5-TSSOP SC-70-5 SOT-353	140 ms	2.63 V	Active Low	1	SC-70-5	Simple Reset/Power-On Reset	Surface Mount	Push-Pull
Analog Devices Inc./Maxim Integrated ADM823TYRJ-R7	125 °C	-40 °C		140 ms	3.08 V	Active Low	1	SOT-23-5	Simple Reset/Power-On Reset	Surface Mount	Push-Pull
Analog Devices Inc./Maxim Integrated ADM823TYRJZ-R7	125 °C	-40 °C		140 ms	3.08 V	Active Low	1	SOT-23-5	Simple Reset/Power-On Reset	Surface Mount	Push-Pull
Analog Devices Inc./Maxim Integrated ADM823SYKS-R7	125 °C	-40 °C	5-TSSOP SC-70-5 SOT-353	140 ms	2.93 V	Active Low	1	SC-70-5	Simple Reset/Power-On Reset	Surface Mount	Push-Pull
Analog Devices Inc./Maxim Integrated ADM823LYRJ-R7	125 °C	-40 °C		140 ms	4.63 V	Active Low	1	SOT-23-5	Simple Reset/Power-On Reset	Surface Mount	Push-Pull
Analog Devices Inc./Maxim Integrated ADM823MYRJZ-R7	125 °C	-40 °C		140 ms	4.38 V	Active Low	1	SOT-23-5	Simple Reset/Power-On Reset	Surface Mount	Push-Pull
Analog Devices Inc./Maxim Integrated ADM823SYRJZ-R7	125 °C	-40 °C		140 ms	2.93 V	Active Low	1	SOT-23-5	Simple Reset/Power-On Reset	Surface Mount	Push-Pull
Analog Devices Inc./Maxim Integrated ADM823SYRJ-R7	125 °C	-40 °C		140 ms	2.93 V	Active Low	1	SOT-23-5	Simple Reset/Power-On Reset	Surface Mount	Push-Pull
Analog Devices Inc./Maxim Integrated ADM823TYKSZ-R7	125 °C	-40 °C	5-TSSOP SC-70-5 SOT-353	140 ms	3.08 V	Active Low	1	SC-70-5	Simple Reset/Power-On Reset	Surface Mount	Push-Pull
Analog Devices Inc./Maxim Integrated ADM823MYKS-R7	125 °C	-40 °C	5-TSSOP SC-70-5 SOT-353	140 ms	4.38 V	Active Low	1	SC-70-5	Simple Reset/Power-On Reset	Surface Mount	Push-Pull
