VT18-8 Series
Manufacturer: Pepperl+Fuchs, Inc.
Beta
⌘K
PHOTO SEN 20-120MM BACK SUPPRESS
| Part | Response Time | Adjustment Type | Connection Method | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) | Output Configuration | Operating Temperature (Max) | Operating Temperature (Min) | Ingress Protection | Sensing Distance Maximum | Sensing Distance Minimum | Light Source | Sensing Method | Light Source Wavelength (Red Laser Diode) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Pepperl+Fuchs, Inc. | 1 ms | Adjustable | Connector M12 | 10 VDC | 30 VDC | Dark-ON Light-ON | 70 °C | -25 °C | IP67 | 4.724 " | 0.787 " | Red LED | Diffuse | |
 Pepperl+Fuchs, Inc. | 1 ms | Adjustable | Connector M12 | 10 VDC | 30 VDC | Dark-ON Light-ON | 70 °C | -25 °C | IP67 | 4.724 " | 0.787 " | Red LED | Diffuse | |
 Pepperl+Fuchs, Inc. | 1 ms | Adjustable | Connector M12 | 10 VDC | 30 VDC | Light-ON\Dark-ON PNP - Open Collector | 70 °C | -25 °C | IP67 | 15.748 " | 0 cm | Red LED | Diffuse | |
 Pepperl+Fuchs, Inc. | 1 ms | Adjustable | Connector M12 | 10 VDC | 30 VDC | Dark-ON Light-ON | 55 °C | -25 °C | IP67 | 15.748 " | 0 cm | Red Laser Diode | Diffuse | 655 nm |
 Pepperl+Fuchs, Inc. | 1 ms | Adjustable | Connector M12 | 10 VDC | 30 VDC | Dark-ON Light-ON | 70 °C | -25 °C | IP67 | 15.748 " | 0 cm | Red LED | Diffuse |
