RTS1BS10 Series

Catalog

RECEPTACLE, INLINE, 6 POSITION,

Part	Operating Temperature (Max)	Operating Temperature (Min)	Ingress Protection IP Rating	Ingress Protection Description	Material Flammability Rating	Shell Size - Insert Length	Shell Size - Insert Width	Contact Size	Fastening Type	Shielding	Includes	Includes Total Count	Contact Type	Contact Shape	Number of Positions	Type	Mounting Type	Shell Material	Insert Material	Note	Orientation	Connector Type	Housing Color	Shell Size - Insert	Primary Material	Features
McGill Microwave Systems RTS1BS10N6PHEC03	125 °C	-40 °C	IP67 IP69K	Dust Tight Water Resistant Waterproof	UL94 V-0	10 mm	6 mm	20	Bayonet Lock	Unshielded	Connector Gasket O-Ring Seal	4 pcs	Crimp	Circular	6	For Male Pins	Free Hanging (In-Line)	Thermoplastic	Thermoplastic	Contacts Not Included	N (Normal)	Receptacle Housing	Black
McGill Microwave Systems RTS1BS10N3W3S03	125 °C	-40 °C	IP67 IP69K	Dust Tight Water Resistant Waterproof	UL94 V-0			16 20	Bayonet Lock	Unshielded			Crimp	Circular	6	For Female Sockets	Free Hanging (In-Line)	Thermoplastic	Thermoplastic	Contacts Not Included	N (Normal)	Receptacle Housing	Black	10-3W3	Plastic	Backshell
McGill Microwave Systems RTS1BS10N6S03	125 °C	-40 °C	IP67 IP69K	Dust Tight Water Resistant Waterproof	UL94 V-0	10 mm	6 mm	20	Bayonet Lock	Unshielded	Backshell Clamp Ring Connector Nut O-Ring Seal	6 pcs	Crimp	Circular	6	For Female Sockets	Free Hanging (In-Line)	Thermoplastic	Thermoplastic	Contacts Not Included	N (Normal)	Receptacle Housing	Black			Backshell
McGill Microwave Systems RTS1BS10N3W3P03	125 °C	-40 °C	IP67 IP69K	Dust Tight Water Resistant Waterproof	UL94 V-0			16 20	Bayonet Lock	Unshielded			Crimp	Circular	6	For Male Pins	Free Hanging (In-Line)	Thermoplastic	Thermoplastic	Contacts Not Included	N (Normal)	Receptacle Housing	Black	10-3W3	Plastic	Backshell
McGill Microwave Systems RTS1BS10N3S03	125 °C	-40 °C	IP67 IP69K	Dust Tight Water Resistant Waterproof	UL94 V-0	10 mm	3 mm	16 S	Bayonet Lock	Unshielded	Backshell Clamp Ring Connector Nut O-Ring Seal	6 pcs	Crimp	Circular	3	For Female Sockets	Free Hanging (In-Line)	Thermoplastic	Thermoplastic	Contacts Not Included	N (Normal)	Receptacle Housing	Black			Backshell
