AD7946 Series

Catalog

DATA CONVERSION IC DEVELOPMENT TOOLS EVALUATION BOARD

Part	Number of A/D Converters	Number of Bits	Sampling Rate (Per Second)	Input Range	Utilized IC / Part	Data Interface	Power (Typ)	Contents	Operating Temperature (Min)	Operating Temperature (Max)	Number of Inputs	Package Name	Mounting Type	Voltage - Supply, Analog	Voltage - Supply, Digital	Ratio - ADC	Ratio - S/H	Configuration	Reference Type	Package Length	Package Width	Architecture	Input Type	Interconnect System	Function	Platform	Type	Package / Case
Analog Devices Inc./Maxim Integrated EVAL-AD7946SDZ	1 count	14 bits	500 kHz	0 ~ VREF	AD7946	DSP MICROWIRE™ QSPI™ Serial SPI™	19 mW	Board
Analog Devices Inc./Maxim Integrated AD7946BRMZ	1 count	14 bits	500 kHz			DSP SPI			-40 °C	85 °C	1	10-MSOP 10-TFSOP	Surface Mount	5 V	5 V	1	1	S/H-ADC	External	0.118 in	3 mm	SAR	Pseudo-Differential
Analog Devices Inc./Maxim Integrated EVAL-AD7946-PMDZ					AD7946			Board																Pmod	Analog to Digital Converter (ADC)	Pmod™	Data Acquisition
Analog Devices Inc./Maxim Integrated AD7946BRMZRL7	1 count	14 bits	500 kHz			DSP SPI			-40 °C	85 °C	1	10-MSOP 10-TFSOP	Surface Mount	5 V	5 V	1	1	S/H-ADC	External	0.118 in	3 mm	SAR	Pseudo-Differential
Analog Devices Inc./Maxim Integrated AD7946BCPZRL7	1 count	14 bits	500 kHz			DSP SPI			-40 °C	85 °C	1	10-LFCSP-WD	Surface Mount	5 V	5 V	1	1	S/H-ADC	External	3 mm	3 mm	SAR	Pseudo-Differential					10-VFDFN Exposed Pad CSP
