ADM2486 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
TRANSCEIVER, RS422, RS485, 20 MBPS, 1 DRIVER, 1 RECEIVER, 2.7 TO 5.5 V, -40 TO 85 °C, WSOIC-16
| Part | Inputs - Side 1 | Inputs - Side 2 | Voltage - Supply | Voltage - Supply | Rise Time (Typ) | Fall Time (Typ) | Operating Temperature (Min) | Operating Temperature (Max) | Isolated Power | Pulse Width Distortion (Max) | Technology | Package Length | Package Name | Package Width | Common Mode Transient Immunity (Min) | Propagation Delay tpHL (Max) | Propagation Delay tpLH (Max) | Data Rate | Number of Channels | Voltage - Isolation | Mounting Type | Channel Type | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | 2 | 1 | 3 V 5 VDC | 3V 5V | 5 ns | 5 ns | -40 °C | 85 °C | No | 5 ns | Magnetic Coupling | 0.295 in | 16-SOIC | 7.5 mm | 25 kV/µs | 55 ns | 55 ns | 20 Mbps | 3 | 2500 Vrms | Surface Mount | Bidirectional | RS422 RS485 |
Analog Devices Inc./Maxim Integrated | 2 | 1 | 3 V 5 VDC | 3V 5V | 5 ns | 5 ns | -40 °C | 85 °C | No | 5 ns | Magnetic Coupling | 0.295 in | 16-SOIC | 7.5 mm | 25 kV/µs | 55 ns | 55 ns | 20 Mbps | 3 | 2500 Vrms | Surface Mount | Bidirectional | RS422 RS485 |
 Analog Devices Inc./Maxim Integrated | 2 | 1 | 3 V 5 VDC | 3V 5V | 5 ns | 5 ns | -40 °C | 85 °C | No | 5 ns | Magnetic Coupling | 0.295 in | 16-SOIC | 7.5 mm | 25 kV/µs | 55 ns | 55 ns | 20 Mbps | 3 | 2500 Vrms | Surface Mount | Bidirectional | RS422 RS485 |
