ACD-14RMMS Series
Manufacturer: McGill Microwave Systems
Beta
⌘K
CERES, MIDDLE SIZE, PLASTIC, 5A, 14 PINS, MALE CONNECTOR, MALE CONTACT, CIRCULAR, 2 POINTS LOCK, SOLDER, RECEPTACLE, IP67 ROHS C
| Part | Contact Material | Connector Type | Contact Finish - Mating | Termination | Insert Material | Shell Size - Insert | Current Rating | Shielding | Primary Material | Voltage Rating | Voltage Rating (Type) | Material Flammability Rating | Ingress Protection Description | Ingress Protection IP Rating | Mounting Type | Color | Shell Material | Number of Positions | Fastening Type | Operating Temperature (Min) | Operating Temperature (Max) | Mounting Feature | Orientation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 McGill Microwave Systems | Copper Alloy | Male Pins Receptacle | Gold | Solder Cup | Glass Filled Nylon PA Polyamide | C | 5 A | Unshielded | Plastic | 250 V | DC | UL94 V-0 | Dust Tight Waterproof | IP67 | Panel Mount | Black | Glass Filled Nylon Polyamide (PA) | 14 | Bayonet Lock | -40 °C | 105 °C | Bulkhead Rear Side Nut | Keyed |
