24624-10 Series

SOL 24V CONT

Catalog

SOL 24V CONT

Part	Coil Resistance	Operating Temperature (Max)	Operating Temperature (Min)	Operate Time	Contact Rating (Current)	Contact Material	Termination Style	Mounting Type	Relay Type	Form A Count	Contact Form	Coil Type	Coil Current	Coil Voltage	Release Time
LITTELFUSE 24624-10	76 Ohms	60 °C	-40 °C	5 ms	100 A	Silver (Ag)	Screw Terminal	Chassis Mount	General Purpose	1	SPST-NO	Non Latching	315.8 mA	24 VDC	5 ms

Catalog

SOL 24V CONT

Description

Ideal for starting small engines in vehicles like lawn tractors, golf carts, and sweepers, this Plastic-Body Continuous-Duty SPST Series Starter Solenoid Relay (24624-10) features a 24 V insulated coil with two 10-32 stud coil terminals. The Cole Hersee solenoid relay has a 100 A continuous current rating, silver contacts, and an L-style metal bracket.
