ADL5372 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
1500 MHZTO 2500 MHZQUADRATURE MODULATOR
| Part | Current - Supply | Function | LO Frequency (Min) | LO Frequency (Max) | Noise Floor | Package Width | Package Name | Package Length | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | P1dB | Output Power | Package / Case | Mounting Type | Test Frequency | RF Frequency (Min) | RF Frequency (Max) | Frequency (Min) | Frequency (Max) | Type | Utilized IC / Part | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | 165 mA | Modulator | 1.5 GHz | 2.5 GHz | -158 dBm/Hz | 4 mm | 24-LFCSP-VQ | 4 mm | 5.25 V | 4.75 V | 14.2 dBm | 7.1 dBm | 24-VFQFN Exposed Pad CSP | Surface Mount | 1.9 GHz | 1.5 GHz | 2.5 GHz | |||||
 Analog Devices Inc./Maxim Integrated | 165 mA | Modulator | 1.5 GHz | 2.5 GHz | -158.5 dBm/Hz | 4 mm | 24-LFCSP | 4 mm | 5.25 V | 4.75 V | 12.4 dBm | 7.1 dBm | 24-WFQFN Exposed Pad CSP | Surface Mount | 1.9 GHz | 1.5 GHz | 2.5 GHz | |||||
 Analog Devices Inc./Maxim Integrated | 1.5 GHz | 2.5 GHz | Modulator | ADL5372 | Board |
