ADM1181A Series

Catalog

EMI/EMC COMPLIANT, ±15 KV ESD PROTECTED, RS-232 LINE DRIVERS/RECEIVERS

Part	Type	Number of Drivers	Number of Receivers	Data Rate	Operating Temperature (Min)	Operating Temperature (Max)	Package Length	Package Name	Package Width	Mounting Type	Duplex	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Protocol	Receiver Hysteresis
Analog Devices Inc./Maxim Integrated ADM1181AARWZ-REEL	Transceiver	2	2	230 kbps	-40 °C	85 °C	0.295 in	16-SOIC	7.5 mm	Surface Mount	Full	5.5 V	4.5 V	RS232	650 mV
Analog Devices Inc./Maxim Integrated ADM1181AANZ	Transceiver	2	2	230 kbps	-40 °C	85 °C	0.3 in	16-DIP 16-PDIP	7.62 mm	Through Hole	Full	5.5 V	4.5 V	RS232	650 mV
Analog Devices Inc./Maxim Integrated ADM1181AARWZ	Transceiver	2	2	230 kbps	-40 °C	85 °C	0.295 in	16-SOIC	7.5 mm	Surface Mount	Full	5.5 V	4.5 V	RS232	650 mV
Analog Devices Inc./Maxim Integrated ADM1181AARW-REEL	Transceiver	2	2				0.295 in	16-SOIC	7.5 mm	Surface Mount		5.5 V	4.5 V	RS232
