AD7983 Series

Catalog

16-BIT, 1.33 MSPS PULSAR ADC IN MSOP/LFCSP

Part	Number of Bits	Input Type	Package Name	Configuration	Ratio - ADC	Ratio - S/H	Voltage - Supply, Analog (Min)	Voltage - Supply, Analog (Max)	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Data Interface	Mounting Type	Reference Type	Sampling Rate (Per Second)	Architecture	Package Length	Package Width	Operating Temperature (Min)	Operating Temperature (Max)	Number of A/D Converters	Number of Inputs	Package / Case
Analog Devices Inc./Maxim Integrated AD7983BRMZ-RL7	16 bits	Pseudo-Differential	10-MSOP 10-TFSOP	S/H-ADC	1	1	2.375 V	2.625 V	2.375 V	2.625 V	DSP SPI	Surface Mount	External	1.33 MHz	SAR	0.118 in	3 mm	-40 °C	85 °C	1 count	1
Analog Devices Inc./Maxim Integrated AD7983BCPZ-RL7	16 bits	Pseudo-Differential	10-LFCSP-WD	S/H-ADC	1	1	2.375 V	2.625 V	2.375 V	2.625 V	DSP SPI	Surface Mount	External	1.33 MHz	SAR	3 mm	3 mm	-40 °C	85 °C	1 count	1	10-VFDFN Exposed Pad CSP
Analog Devices Inc./Maxim Integrated AD7983BCPZ-R2	16 bits		10-LFCSP-WD									Surface Mount				3 mm	3 mm					10-VFDFN Exposed Pad CSP
Analog Devices Inc./Maxim Integrated AD7983BRMZ	16 bits	Pseudo-Differential	10-MSOP 10-TFSOP	S/H-ADC	1	1	2.375 V	2.625 V	2.375 V	2.625 V	DSP SPI	Surface Mount	External	1.33 MHz	SAR	0.118 in	3 mm	-40 °C	85 °C	1 count	1
