ADL5591 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
1805 MHZTO 1990 MHZQUADRATURE MODULATOR
| Part | RF Frequency (Min) | RF Frequency (Max) | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Package Name | Package Length | Package Width | Current - Supply | Package / Case | Noise Floor | Mounting Type | Output Power | Test Frequency | Function | P1dB |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | 1.805 GHz | 1.99 GHz | 5.25 V | 4.75 V | 36-LFCSP-VQ | 6 mm | 5.75 mm | 170 mA | 36-VFQFN Exposed Pad CSP | -157 dBM/Hz | Surface Mount | 4.7 dBm | 1.96 GHz | Modulator | 16 dBm |
